Sick WFM80-60N321 Fork Sensor
The WFM80-60N321 Sick Fork Sensor provides 80 mm fork width, 60 mm fork depth, and NPN switching output for label detection. This Sick WFM80-60N321 Sick Fork Sensor detects 2 mm minimum label gaps, supports teach-in adjustment via button and cable, offers 100 mA output current, light/dark switching mode, M8 3-pin connector, aluminum housing, and integrated reverse polarity and short-circuit protection.
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WFM80-60N321 |
Sick WFM80-60N321 Fork Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 10 mm x 100 mm x 77.5 mm |
| Fork width | 80 mm |
| Fork depth | 60 mm |
| Minimum detectable object (MDO) | Gap between Labels / Size of labels: 2 mm 1) |
| Adjustment | Teach-in button, cable (Teach-in, sensitivity, light/dark switching, key lock, Teach-in dynamic) |
| Switching output | NPN |
| Switching output (voltage) | PNP: HIGH = VS – ≤ 1.5 V / LOW = 0 VNPN: HIGH = approx. VS / LOW ≤ 1.5 V |
| Switching mode | Light/dark switching |
| Output current Imax. | 100 mA |
| Connection type | Connector M8, 3-pin |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
| Weight | Approx. 36 g |
| Housing material | Aluminum |
The WFM80-60N321 Sick Fork Sensor is designed for precise label detection in industrial automation systems. The WFM80-60N321 Sick Fork Sensor features 80 mm fork width, 60 mm fork depth, NPN switching output, and 2 mm minimum detectable object capability. It belongs to the WFE series and uses an optical detection principle with teach-in sensitivity adjustment. This configuration supports consistent signal output for PLC-based control systems.
In packaging machines, conveyor systems, and automated labeling lines, the WFM80-60N321 ensures stable detection of label edges and gaps. Light/dark switching mode allows flexible installation, while the 100 mA output current enables direct interface with industrial controllers. The M8 3-pin connector simplifies wiring, and built-in electrical protection supports reliable operation in electrically noisy environments.
The WFM80-60N321 Sick Fork Sensor combines defined fork geometry and NPN output for controlled sensing tasks. With dimensions of 10 mm x 100 mm x 77.5 mm and aluminum housing, this Sick Fork Sensor model WFM80-60N321 integrates into compact automation assemblies. As part of the Sick sensing range, it provides dependable performance for industrial labeling, packaging, and assembly applications.
