WF2-60B416: 6028457 - Sick 32 mm PNP NPN Fork Sensor
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WF2-60B416 |
Sick 32 mm PNP NPN Fork Sensor WF2-60B416, 6028457 Technical Specifications:
| Specification | Value |
|---|---|
| Functional principle | Fork sensor |
| Dimensions (W x H x D) | 10 mm x 32 mm x 74 mm |
| Fork width | 2 mm |
| Fork depth | 59 mm |
| Minimum detectable object (MDO) | 0.2 mm |
| Light Source | LED, infrared |
| Adjustment | Plus/minus button (Sensitivity, light/dark switching, key lock) |
| Current consumption | - |
| Switching frequency | 10 kHz 1) |
| Stability of response time | ± 20 µs |
| Switching output | PNP/NPN |
| Switching output (voltage) | PNP: HIGH = VS – ≤ 1.5 V / LOW = 0 V, NPN: HIGH = approx. VS / LOW ≤ 1.5 V |
| Switching mode | Light/dark switching |
| Switching output hysteresis | - |
| Output current Imax. | 100 mA |
| Initialization time | - |
| Connection type | Male connector M8, 4-pin |
| Protection class | III 4) |
| Circuit protection | UV connections, reverse polarity protected, Output Q short-circuit protected, Interference pulse suppression |
| Enclosure rating | IP65 |
| Housing material | Metal, Aluminum |
The WF2-60B416 Sick 32 mm PNP NPN Fork Sensor is designed for precise object detection in industrial automation systems. This WF2-60B416 model combines a 2 mm fork width, 59 mm fork depth, 10 kHz switching frequency, and PNP/NPN output to support consistent signal performance. As part of the WFE series, it is commonly integrated into automated sensing environments requiring compact fork dimensions.
Typical applications for the WF2-60B416 Sick 32 mm PNP NPN Fork Sensor include conveyors, packaging machines, automated assembly lines, and material handling systems. The fork sensor structure ensures stable alignment across the sensing gap, while infrared LED technology supports reliable detection of small objects during continuous operation.
The WF2-60B416 fork sensor from Sick features a metal housing with IP65 enclosure rating and integrated circuit protection to support long-term industrial use. Standard M8 connectivity, controlled output current, and stable response characteristics reinforce dependable electrical integration. These specifications confirm its suitability for demanding industrial automation environments.
