Sick UM30-211118 Ultrasonic Sensor
The Sick UM30-211118 Ultrasonic Sensor offers Cylindrical
, design LED display, 2 x LED
indication, Straight sending axis, Male connector, M12, 5-pin
connection. Manufactured by Sick under the Sick Ultrasonic Sensor category, this model belongs to the UM Series.
| Brand | Sick |
| Product Type | Ultrasonic Sensor |
| Product | UM30-211118 |
Sick UM30-211118 Ultrasonic Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Design | Cylindrical |
| Supply voltage Vs | DC 9 V ... 30 V |
| Power consumption | ≤ 2.4 W |
| Initialization time | < 300 ms |
| Housing material | Metal (nickel-plated brass, PBT, ultrasonic transducer: polyurethane foam, glass epoxy resin) |
| Connection type | Male connector, M12, 5-pin |
| Indication | LED display, 2 x LED |
| Sending axis | Straight |
| Dimensions (W x H x D) | 30 mm x 30 mm x 84 mm |
| Enclosure rating | IP65 / IP67 |
| Weight | 150 g |
IndMALL offers the Sick DC 9 V Ultrasonic Sensor UM30-211118 part no: 6036921 at affordable rates. Check out the UM30-211118 Datasheet for detailed specifications. This sensor features a cylindrical design with a DC 9 V ... 30 V supply voltage and ≤ 2.4 W power consumption. It has an initialization time of < 300 ms and is made of high-quality materials like nickel-plated brass, PBT, polyurethane foam, and glass epoxy resin. The sensor includes a male connector (M12, 5-pin) and a 2 x LED display for indication. Its dimensions are 30 mm x 30 mm x 84 mm. Get a quote for your requirement of Sick DC 9 V Ultrasonic Sensor UM30-211118 and request the UM30-211118 Manual for further details. Our better pricing and exceptional support make us the preferred choice over other distributors.
