Sick RAY10-PZ3EBL Photoelectric Sensor
The RAY10-PZ3EBL Sick Reflex Array Photoelectric Sensor detects 5 mm objects across a 25 mm uniform light array.
This SICK model belongs to the SICK Photoelectric Sensor range and SICK RAY10 Reflex Array series, providing 0 m to 1.5 m sensing.
RAY10-PZ3EBL, Part No. 1100989, provides PNP light-switching output, 10–30 V DC supply, 0.5 ms response time, PinPoint red LED, 1-metre cable with 4-pin M8 connector, potentiometer adjustment, and IP67 protection.
| Brand | Sick |
| Product Type | Photoelectric Sensor |
| Model Number | RAY10-PZ3EBL |
Sick RAY10-PZ3EBL Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Functional principle | Photoelectric retro-reflective sensor |
| Functional principle detail | Dual lens, Reflex Array |
| Dimensions (W x H x D) | 21.5 mm x 36 mm x 37.7 mm |
| Housing design (light emission) | Rectangular |
| Minimum object size | 5 mm, position-independent detection within the light array |
| Detection height | 25 mm |
| Sensing range max. | 0 m ... 1.5 m |
| Distance of the sensor to reflector | 0.3 m ... 1.5 m |
| Conveyor belt suppression | - |
| Type of light | Visible red light |
| Light source | PinPoint LED 2) |
| Light spot size (distance) | 37 mm x 12 mm (1 m) |
| Wave length | 635 nm |
| Adjustment | Potentiometer |
| Pin 2 configuration | - |
| Supply voltage UB | 10 V DC ... 30 V DC |
| Ripple | < 5 Vpp |
| Current consumption | 30 mA 2) |
| Switching Output | PNP |
| Output: QL1 / C | - |
| Output function | - |
| Switching mode | Light switching |
| Switching mode selector | - |
| Signal voltage PNP HIGH/LOW | Approx. VS – 2.5 V / 0 V |
| Signal voltage NPN HIGH/LOW | Approx. VS / < 2.5 V |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 0.5 ms |
| Switching frequency | 1,000 Hz |
| Connection type | Cable with M8 male connector, 4-pin, 1 m |
| Cable material | PVC |
| Protection class | - |
| Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP66, IP67 |
| Ambient operating temperature | –40 °C ... +60 °C 10) |
| Ambient temperature, storage | –40 °C ... +70 °C |
| Weight | 130 g |
The RAY10-PZ3EBL Sick Reflex Array Photoelectric Sensor is a SICK retro-reflective sensor for object detection in industrial automation. It provides a 0 m to 1.5 m sensing range, detects objects as small as 5 mm, uses a 25 mm detection height, and provides a PNP light-switching output. The RAY10-PZ3EBL belongs to the SICK RAY10 Reflex Array series and uses a dual-lens Reflex Array system with visible PinPoint red LED light.
The RAY10-PZ3EBL Sick Reflex Array Photoelectric Sensor can be used on conveyors, packaging machines, automated production equipment, and assembly systems. Its 25 mm light array supports detection of uneven, flat, transparent, or perforated objects within the sensing area. The 0.5 ms response time supports rapid object detection, while the manual potentiometer allows sensitivity adjustment. Its 10–30 V DC supply and 4-pin M8 connection support integration into industrial automation systems.
SICK RAY10-PZ3EBL, Part No. 1100989, combines Reflex Array sensing, PNP light-switching output, visible PinPoint LED illumination, and a 1-metre cable with a 4-pin M8 male connector. The sensor operates from 10–30 V DC and carries an IP67 enclosure rating for dust and water protection. As part of the SICK RAY10 Reflex Array range, this model is suited to conveyor, packaging, assembly, and automation applications requiring detection of small or irregularly shaped objects.
