Sick IQ12-04BNSKT0S Proximity Sensor
The Sick IQ12-04BNSKT0S Proximity Sensor offers a Rectangular, 4 mm sensing range, Flush installation type, NPN NO output, and Connector M8, 3-pin connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IQ Series.
| Brand | Sick |
| Product Type | Proximity Sensor |
| Model Number | IQ12-04BNSKT0S |
Sick IQ12-04BNSKT0S Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Housing | Rectangular |
| Dimensions (W x H x D) | 12 mm x 40 mm x 26 mm |
| Sensing range Sn | 4 mm |
| Safe sensing range Sa | 3.24 mm |
| Installation type | Flush |
| Switching frequency | 2,000 Hz |
| Connection type | Connector M8, 3-pin |
| Switching output | NPN |
| Output function | NO |
| Electrical wiring | DC 3-wire |
| Enclosure rating | IP68 1) |
| Supply voltage | 10 V DC ... 30 V DC |
| Ripple | β€ 10 % 1) |
| Voltage drop | β€ 2 V 2) |
| Time delay before availability | β€ 100 ms |
| Hysteresis | 5 % ... 15 % |
| Reproducibility | β€ 2 % 3) 4) |
| Temperature drift (of Sr) | Β± 10 % |
| Continuous current Ia | β€ 200 mA |
| No load current | 10 mA |
| Ambient operating temperature | β25 Β°C ... +75 Β°C |
| Tightening torque, max. | β€ 1 Nm |
| Unit weight | 20.200 Grams |
| Net unit weight | 20.2 Grams |
| Unit volume | 21 Cubic Centimetres (cmΒ³) |
| Country of origin | Malaysia |
