Sick IMB12-04BNPVC0K Proximity Sensor

Name: Sick IMB12-04BNPVC0K
Brand: IndMALL
SKU: 8d216a0fe59e
Rating: 4.4 (4 reviews)

The Sick IMB12-04BNPVC0K Proximity Sensor offers a Metric; Short-body, 4 mm sensing range, Flush installation type, NPN Complementary output, and Male connector M12, 4-pin 1) connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IMB Series.

Datasheet

Brand	Sick
Product Type	Proximity Sensor
Model Number	IMB12-04BNPVC0K

Sick IMB12-04BNPVC0K Proximity Sensor – Technical Specifications

Specification	Value
Housing	Metric; Short-body
Thread size	M12 x 1
Diameter	Ø 12 mm
Sensing range Sn	4 mm
Safe sensing range Sa	3.24 mm
Installation type	Flush
Switching frequency	2,000 Hz
Connection type	Male connector M12, 4-pin 1)
Switching output	NPN
Output function	Complementary
Electrical wiring	DC 4-wire
Enclosure rating	IP68 2)IP69K 3)
Special features	Resistant against coolant lubricants, Temperature resistance
Special applications	Zones with coolants and lubricants, Mobile machines, Difficult application conditions
Items supplied	Mounting nut, V2A stainless steel, with locking teeth (2x)
Supply voltage	10 V DC ... 30 V DC
Ripple	≤ 10 %
Voltage drop	≤ 2 V 1)
Hysteresis	3 % ... 20 %
Reproducibility	≤ 2 % 2) 3)
Temperature drift (of Sr)	± 10 %
Continuous current Ia	≤ 200 mA
No load current	≤ 10 mA
Ambient operating temperature	–40 °C ... +100 °C
Housing material	Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material	Plastic, LCP
Housing length	45 mm
Thread length	28 mm
Tightening torque, max.	Typ. 20 Nm 4)Typ. 32 Nm 5)
Protection class	III
Unit weight	28.000 Grams
Net unit weight	28 Grams
Country of origin	Hungary
