Sick DOL-2312-G10MMA3: Sensor Actuator Cable
Technical Specifications of Sick Sensor Actuator Cable DOL-2312-G10MMA3:
| Cable | 10 m, 12-wire, PUR, halogen-free |
| Cable diameter | 7.8 mm |
| Reference voltage | ≤ 160 V |
| Current loading | 7 A |
Sick Sensor Actuator Cable DOL-2312-G10MMA3 Technical Specifications
| Specification | Value |
|---|
| Connection type head A | Female connector, M23, 12-pin, straight |
| Connection type head B | Flying leads |
| Connector material | TPU |
| Connector color | Black |
| Cable | 10 m, 12-wire, PUR, halogen-free |
| Jacket material | PUR, halogen-free |
| Jacket color | Black |
| Cable diameter | 7.8 mm |
| Conductor cross section | 4 x 2 x 0.25 mm² + 2 x 0.5 mm² + 2 x 0.14 mm² |
| Shielding | Shielded |
| Reference voltage | ≤ 160 V |
| Current loading | 7 A |
| Signal type | Incremental |
| Operating temperature Flexible use | –5 °C ... +80 °C |
| Operating temperature Stationary position | > 5 x cable diameter |
| Operating temperature Head | –25 °C ... +85 °C |
