Schmersal ZV3H 015-11Y Limit Switch
The Schmersal ZV3H 015-11Y Limit Switch (Item No: 131055306) offers a mechanical working principle, Light-alloy diecast, paint finishhousing material, 43 mm length of sensor, IP65 degree of protection. Manufactured by Schmersal under the Schmersal Limit Switch. category, this model belongs to the Schmersal TV Series.
| Brand | Schmersal |
| Product Type | Limit Switch |
| Model Number | ZV3H 015-11Y |
Schmersal ZV3H 015-11Y Limit Switch – Technical Specifications
| Specification | Value |
|---|---|
| Working principle | mechanical |
| Slide form | Castor |
| Housing material | Light-alloy diecast, paint finish |
| Housing coating material | painted |
| Gross weight | 439 g |
| Number of normally closed (NC) | - |
| Number of normally open (NO) | - |
| Actuating element | Roller lever |
| Roller material | Plastic |
| Actuating angle, from left of switch axis | 30 ° |
| Actuating angle, from right of switch axis | 30 ° |
| Contact opening | - |
| Actuating speed, minimum | 1 mm/min |
| Actuating speed, maximum | 3 m/s |
| Length of sensor | 43 mm |
| Width of sensor | 67 mm |
| Height of sensor | 171 mm |
| Width of Castor | 8 mm |
| Diameter of Castor | 36 mm |
| Degree of protection | IP65 |
| Ambient temperature | -30 ... +90 °C |
| Rated insulation voltage Ui | - |
| Thermal test current | 10 A |
| Utilisation category AC-15 | - |
| Switching element | - |
| Switching principle | - |
| Material of the contacts, electrical | Silver |
Get A Quote for Medium-duty position switches ZV3H 015-11Y part no: 131055306 at the best price. Here are the brief Technical Specifications of ZV3H 015-11Y, 131055306 are Light-alloy diecast, paint finish, ensuring durability in industrial environments. The switch features a Roller lever actuating element, providing precise mechanical operation. With a gross weight of 439 g, it maintains a compact yet robust design. The connection technique supports wire cross-section, ensuring reliable electrical connections. Dimensions include a sensor length of 43 mm, width of 67 mm, and height of 171 mm. The castor width is 8 mm, with a diameter of 36 mm, enhancing mechanical efficiency. The unit is rated IP65, offering protection against dust and water ingress. Designed for high-voltage applications, it features a rated insulation voltage (Ui) of -, ensuring electrical safety. It's Time to get a Quote for your requirement of Medium-duty position switches . We guarantee unmatched pricing and unparalleled support compared to other Distributors.
