PSC1-C-100-FB20: 103049455 - Schmersal FB20 Integrated Safety Controller
Tecchnical Specifications of Schmersal FB20 Integrated Safety Controller PSC1-C-100-FB20 103049455:
| Spec | Value |
|---|---|
| PFH value | 1.22 x 10⁻⁸ /h |
| Mounting | can be clipped into standard rail |
| Terminal (mechanical) | Removable screw terminals |
| Rated Operating Voltage | 24 VDC |
Schmersal FB20 Integrated Safety Controller PSC1-C-100-FB20, 103049455 Technical Specifications:
| Specification | Value |
|---|---|
| PFH value | 1.22 x 10⁻⁸ /h |
| Mounting | can be clipped into standard rail |
| Cable section, minimum | 0.2 mm² |
| Cable section, maximum | 2.5 mm² |
| Wire cross-section, minimum | 24 AWG |
| Wire cross-section, maximum | 12 AWG |
| Wire cross-section | 24 ... 12 AWG |
| Terminal (mechanical) | Removable screw terminals |
| Width | 112.5 mm |
| Height | 100 mm |
| Depth | 115 mm |
| Degree of protection | IP20 |
| Ambient temperature | 0 ... +50 °C |
| Storage and transport temperature | -25 ... +70 °C |
| Relative humidity, minimum | 5 % |
| Relative humidity, maximum | 85 % |
| Permissible installation altitude above sea level, maximum | 2,000 m |
| Operating voltage | 24 VDC -15 % / +20 % |
| Rated operating voltage | 24 VDC |
| Designation, Communication interface | DSUB |
| Rated operating current (safety outputs) | 2,000 mA |
| Design of control elements | short-circuit proof, p-type (Q2 und Q3) |
| Gross weight | 940 g |
Get A Quote for Schmersal FB20 Integrated Safety Controller PSC1-C-100-FB20 part no: 103049455 at the best price. Here are the brief Technical Specifications of PSC1-C-100-FB20, 103049455 are PFH value of 1.22 x 10⁻⁸ /h ensuring high safety integrity. Designed for easy installation, it can be clipped into standard rail with Removable screw terminals providing secure connections. The controller operates at a rated voltage of 24 VDC and supports a rated operating current of 2,000 mA making it suitable for various industrial applications. Its compact design includes a height of 100 mm and depth of 115 mm fitting seamlessly into tight spaces. The controller is IP20 rated, offering protection against solid objects, and weighs 940 g. It's Time to get a Quote for your requirement of Schmersal FB20 Integrated Safety Controller. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
