Schmersal MR 330-11Y-M20-1366 Limit Switch
The Schmersal MR 330-11Y-M20-1366 Limit Switch (Item No: 131162603) offers a mechanical working principle, Light-alloy diecast, paint finishhousing material, 40 mm length of sensor, IP65 degree of protection. Manufactured by Schmersal under the Schmersal Limit Switch. category, this model belongs to the Schmersal TV Series.
| Brand | Schmersal |
| Product Type | Limit Switch |
| Model Number | MR 330-11Y-M20-1366 |
Schmersal MR 330-11Y-M20-1366 Limit Switch – Technical Specifications
| Specification | Value |
|---|---|
| Working principle | mechanical |
| Housing material | Light-alloy diecast, paint finish |
| Housing coating material | painted |
| Gross weight | 190 g |
| Actuating element | Roller plunger |
| Roller material | Brass |
| Actuating speed, minimum | 1 mm/min |
| Actuating speed, maximum | - |
| Connection technique - Wire cross-section | 13 AWG |
| Length of sensor | 40 mm |
| Width of sensor | 40 mm |
| Height of sensor | 116.5 mm |
| Width of Castor | 4.6 mm |
| Diameter of Castor | 17.2 mm |
| Degree of protection | IP65 |
| Ambient temperature | -30 ... +160 °C |
| Rated insulation voltage Ui | 250 VAC |
| Thermal test current | 6 A |
| Utilisation category AC-15 | 2.5 A |
| Material of the contacts, electrical | Silver |
Give Us a Call for Medium-duty position switches MR 330-11Y-M20-1366 part no: 131162603 at the lowest pricing. In-depth Technical Analysis of MR 330-11Y-M20-1366, 131162603 feature Light-alloy diecast, paint finish, ensuring durability in industrial environments. The switch features a Roller plunger actuating element, providing precise mechanical operation. With a gross weight of 190 g, it maintains a compact yet robust design. The connection technique supports 13 AWG wire cross-section, ensuring reliable electrical connections. Dimensions include a sensor length of 40 mm, width of 40 mm, and height of 116.5 mm. The castor width is 4.6 mm, with a diameter of 17.2 mm, enhancing mechanical efficiency. The unit is rated IP65, offering protection against dust and water ingress. Designed for high-voltage applications, it features a rated insulation voltage (Ui) of 250 VAC, ensuring electrical safety. Elevate Your Project with a Quote for your requirement of Medium-duty position switches . Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
