Schmersal IFL 2-8M-01ST2P Photo-electric Proximity Switches
The Schmersal IFL 2-8M-01ST2P Photoelectric Proximity Switches (Item No: 101117678) offers a Cylinder, thread housing construction form, Connector M8termination, 10 ... 30 VDC rated operating voltage, Opener (NC) switching element. Manufactured by Schmersal under the Schmersal Photoelectric Proximity Switches. category, this model belongs to the Schmersal IF Series.
| Brand | Schmersal |
| Product Type | Photo-electric Proximity Switch |
| Model Number | IFL 2-8M-01ST2P |
Schmersal IFL 2-8M-01ST2P Photo-electric Proximity Switches β Technical Specifications
| Specification | Value |
|---|---|
| Housing construction form | Cylinder, thread |
| Housing material | Brass |
| Active area | Plastic |
| Material of the nuts | Brass |
| Gross weight | 30 g |
| Integral system diagnostics, status | Yes |
| Number of cable wires | 3 |
| Tightening torque of nuts, maximum | 6 Nm |
| Termination | Connector M8 |
| ISO thread of the sensor | M8 |
| width across flats | 13 BK |
| Length of sensor | 54 mm |
| Degree of protection | IP67 |
| Type of voltage range | DC |
| Rated operating voltage | 10 ... 30 VDC |
| Operating current | 200 mA |
| Switching element | Opener (NC) |
| Protection circuit integrated | inductive interference protectionProtection against polarity reversalSurge protectionMax. fuse rating |
| Switching frequency, approx. | 3,000 Hz |
| Voltage drop Ud, maximum | 1.2 V |
| Current at Voltage drop Ud | 0.2 A |
| Design of control elements | p-type |
| Note (Integral System Diagnostics, status ) | yellow LED |
Give Us a Call for Schmersal Inductive Proximity Switches IFL 2-8M-01ST2P part no: 101117678 at the lowest pricing. In-depth Technical Analysis of IFL 2-8M-01ST2P, 101117678 feature Cylinder, thread Brass housing, ensuring lightweight durability for industrial applications. Designed for versatile electrical compatibility, it operates at a rated voltage of 10 ... 30 VDC with a maximum operating current of 200 mA. The switching element supports both Opener (NC), allowing flexible configurations. With an approximate switching frequency of 3,000 Hz, it ensures reliable performance in automation setups. The maximum voltage drop (Ud) is 1.2 V, with a current rating of 0.2 A at Ud, providing efficient electrical conductivity. The control element features an p-type design, ensuring simplified wiring for seamless integration. Termination is achieved via a Connector M8, ensuring secure and stable electrical contacts. The unit is IP67 rated, offering protection against dust and low-pressure water jets. Elevate Your Project with a Quote for your requirement of Inductive Proximity Switches. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
