BNS 260-02/01ZG-ST-L: 101184382 - Schmersal Adjustable Sensing Safety Sensors
Technical Specifications of Adjustable Sensing Safety Sensors BNS 260-02/01ZG-ST-L 101184382:
| Working principle | Magnetic drive |
| Termination | Connector 8 mm, 6-pole, Latching interlocking |
| Degree of Protection | IP67 |
Schmersal Adjustable Sensing Safety Sensors, BNS 260-02/01ZG-ST-L, 101184382 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | Quasi Flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 3 |
| Number of safety contacts | 2 |
| Actuating element | Magnet |
| Door hinge | Left |
| Direction of motion | Head-on to the active surface |
| Assured switching distance "ON" Sao | 5 mm |
| Assured switching distance "OFF" Sar | 15 mm |
| Termination | Connector 8 mm, 6-pole, Latching interlocking |
| Length of sensor | 13 mm |
| Width of sensor | 26 mm |
| Height of sensor | 36 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 °C |
| Storage and transport temperature | -25 ... +70 °C |
| Resistance to vibrations | 10 … 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Rated insulation voltage Ui | 75 VDC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Required rated short-circuit current | 100 A |
| Switching voltage, maximum | 24 VDC |
| Switching current, maximum | 0.01 A |
| Switching capacity, maximum | 0.24 W |
| Switching element | 3 NC contact |
| Switching frequency, maximum | 5 Hz |
| Gross weight | 33 g |
Call Us for Adjustable Sensing Safety Sensors BNS 260-02/01ZG-ST-L at the Best Rates
Contact us for a quote on Adjustable Sensing Safety Sensors BNS 260-02/01ZG-ST-L (Part No: 101184382) at exclusive pricing.
Technical Specifications of BNS 260-02/01ZG-ST-L
Magnetic Drive Principle
Housing: Durable Glass-fibre, reinforced thermoplastic for maximum durability and reliability
Actuating Element: Magnet, optimized for smooth operation with 5 mm and 15 mm switching distances for accurate performance
Connector: Features 8 mm, 6-pole, Latching interlocking termination for easy installation and a secure connection
Electrical Ratings: Supports 24 VDC maximum switching voltage, 0.01 A current, with a switching frequency of up to 5 Hz
Protection: Rated IP67, providing excellent resistance to dust and water
