Schmersal AZ 16 ZVRK-STL Safety Switch with Separate Actuator

The Schmersal AZ 16 ZVRK-STL Safety switch with separate actuator (Item No: 101180846) offers a Electromechanical working principle, 1 number of safety contacts, IP67 degree of protection, 1 NO contact, 1 NC contacts switching element. Manufactured by Schmersal under the Schmersal Safety switch with separate actuator. category, this model belongs to the Schmersal AZ Series.

Schmersal AZ 16 ZVRK-STL 101180846
BrandSchmersal
Product TypeSafety Switch with Separate Actuator
Model NumberAZ 16 ZVRK-STL

Schmersal AZ 16 ZVRK-STL Safety Switch with Separate Actuator – Technical Specifications

SpecificationValue
Working principleElectromechanical
Housing materialPlastic, glass-fibre reinforced thermoplastic, self-extinguishing
Housing coating material-
Number of safety contacts1
Number of cable glands3
B10D Normally-closed contact (NC)2,000,000 Operations
B10D Normally-open contact (NO)-
Latching force-
Positive break travel8 mm
Positive break force per NC contact, minimum10 N
Positive break force, minimum-
Actuating speed, maximum2 m/s
MountingScrews
Type of the fixing screws2x M6
Tightening torque of the fixing screws-
Tightening torque of the fastening screws for the housing cover-
TerminationConnector plug M12, 4-pole, (A-coding)
Length of sensor30 mm
Width of sensor52 mm
Height of sensor90 mm
Degree of protectionIP67
Ambient temperature-30 ... +80 °C
Storage and transport temperature-40 ... +85 °C
Rated insulation voltage Ui500 V
Rated impulse withstand voltage Uimp-
Thermal test current10 A
Required rated short-circuit current1,000 A
Switching element1 NO contact, 1 NC contacts
Switching principleslow action, positive break NC contact
Maximum switching frequency4,000 /h
Material of the contacts, electricalSilver
Gross weight130 g
Ask for the Pricing of Schmersal Safety Switch with Durable Thermoplastic Enclosure AZ 16 ZVRK-STL part no: 101180846 at unbeatable prices. Detailed Specifications of AZ 16 ZVRK-STL, 101180846 feature Electromechanical working principle. The switch features a robust housing made of Plastic, glass-fibre reinforced thermoplastic, self-extinguishing ensuring durability in industrial environments. It comes with 1 safety contacts, with a B10D rating of 2,000,000 Operations for normally-closed (NC) contacts and - for normally-open (NO) contacts. The switch provides a latching force of - and is mounted using Screws with secure Connector plug M12, 4-pole, (A-coding) for termination. It operates at a rated insulation voltage of 500 V and includes 1 NO contact, 1 NC contacts switching elements, with a maximum switching frequency of 4,000 /h. The switch is protected with IP67 ratings, making it suitable for harsh conditions, and can operate in ambient temperatures ranging from -30 ... +80 °C. Now's the Time to Secure a Quote for your requirement of Schmersal Safety Switch with Durable Thermoplastic Enclosure. We're committed to offering more favorable pricing and more responsive support than other Traders.
