Schmersal AZ 05 K 08106 Positive-operation Door Contacts
The Schmersal AZ 05 K 08106 Positive-operation Door Contacts (Item No: 101195810) offers a 1,000,000 Operations mechanical life, minimum, IP00 degree of protection, 500 V rated insulation voltage Ui, Opener (NC) switching element. Manufactured by Schmersal under the Schmersal Positive-operation Door Contacts. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Positive-operation Door Contact |
| Model Number | AZ 05 K 08106 |
Schmersal AZ 05 K 08106 Positive-operation Door Contacts – Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Gross weight | 35 g |
| Suitable for elevators | Yes |
| Number of safety contacts | 1 |
| Mechanical life, minimum | 1,000,000 Operations |
| Termination | Screw terminals M20 x 1.5 |
| Degree of protection | IP00 |
| Ambient temperature | -15 ... +70 °C |
| Rated insulation voltage Ui | 500 V |
| Thermal test current | 4 A |
| Switching element | Opener (NC) |
| Switching principle | Self-cleaning pressure contact |
| Material of the contacts, electrical | Silver-plated Cu rivets |
| Scope of delivery | Actuator must be ordered separately. |
| Standards | EN 81 |
| Material of the housing cover | transparent thermoplastic, self-extinguishing |
| Actuating panels | 1 |
| Actuating stroke | 5 mm |
| Actuating force, approx. | 1.6 N |
| Mounting | Round holes |
| Cable entry | Single wire entry |
| Connection technique - Notes | - |
| Width | 72 mm |
| Height | 40 mm |
| Depth | 26 mm |
IndMALL Automation Dealing offers Schmersal Positive-operation Door Contacts AZ 05 K 08106 Item No: 101195810 at unbeatable prices. The Main Technical Parameters of AZ 05 K 08106, 101195810 feature housing is made of Plastic, glass-fibre reinforced thermoplastic, self-extinguishing to enhance fire resistance. Electrical termination is achieved through robust Screw terminals M20 x 1.5 entries, ensuring secure connections in demanding environments. Rated IP00, the device provides excellent protection against dust and water ingress, making it suitable for harsh operating conditions. It operates efficiently in ambient temperatures ranging from -15 ... +70 °C. The control panel features a rated insulation voltage (Ui) of 500 V and supports a thermal test current of up to 4 A. The switching element is an Opener (NC), operating on an Self-cleaning pressure contact principle for precise and stable operation. Electrical contacts are made of high-quality Silver-plated Cu rivets for enhanced conductivity and long service life. Take the First Step with a Quote for your requirement of Positive-operation Door Contacts AZ 05 K 08106. Choose us for unparalleled pricing and support over other Dealers & Distributors.
