RIF-3-RPT-LV-230AC/3X21: 2903292 - Phoenix 3 Changeover Relay Module
Technical Specifications of Phoenix 3 Changeover Relay Module RIF-3-RPT-LV-230AC/3X21 2903292:
Spec | Value |
---|---|
Product type | Relay Module |
Nominal input voltage UN | 230 V AC |
Connection method | Push-in connection |
Mounting type | DIN rail mounting |
Phoenix 3 Changeover Relay Module RIF-3-RPT-LV-230AC/3X21, 2903292 Technical Specifications:
Specification | Value |
---|---|
Product type | Relay Module |
Product family | RIFLINE complete |
Application | Universal |
Mechanical service life | approx. 2x 107 cycles |
Insulation | Basic insulation |
Overvoltage category | III |
Pollution degree | 2 |
Maximum power dissipation for nominal condition | 3 W |
Test voltage (Winding/contact) | 2.5 kVrms (50 Hz, 1 min., winding/contact) |
Test voltage (Changeover contact/changeover contact) | - |
Rated surge voltage | 4 kV |
Nominal input voltage UN | 230 V AC |
Input voltage range | 195.5 V AC ... 253 V AC (20 °C) |
Drive and function | monostable |
Drive (polarity) | polarized |
Typical input current at UN | 13 mA |
Typical response time | 5 ms ... 15 ms |
Typical release time | - |
Protective circuit | Varistor |
Operating voltage display | Yellow LED |
Contact switching type | 3 changeover contacts |
Type of switch contact | Single contact |
Contact material | AgNi |
Maximum switching voltage | 250 V AC/DC |
Limiting continuous current | 6 A (see diagram) |
Maximum inrush current | 30 A (20 ms, N/O contacts) |
Min. switching current | 10 mA (24 V) |
Interrupting rating (ohmic load) max. | 144 W (24 V DC) |
Switching capacity | - |
Connection method | Push-in connection |
Stripping length | 8 mm |
Conductor cross section rigid | 0.14 mm² ... 1.5 mm² |
Conductor cross section flexible | 0.14 mm² ... 1.5 mm² |
Conductor cross section AWG | 26 ... 16 (solid) |
Tightening torque | - |
Width | 40 mm |
Height | 103 mm |
depth | 90 mm |
Color | gray (RAL 7042) |
Flammability rating according to UL 94 | V2 (Housing) |
Degree of protection (Relay) | RT I (Relay) |
Degree of protection (Relay base) | IP20 (Relay base) |
Ambient temperature (operation) | -40 °C ... 50 °C |
Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Temperature | - |
Humidity | - |
Vibration | - |
EMC | - |
Enclosure | - |
Low Voltage Directive | - |
Electromagnetic compatibility | - |
Standards/regulations | IEC 60947-5-1 |
Mounting Type | DIN rail mounting |
Mounting position | any |
Contact Connection type | - |
Output fuse | - |
Degree of protection (Installation location) | - |
