PLC-RPT- 60DC/21-21AU: 2900341 - Phoenix DIN Rail Mounting Relay
Technical Specifications of Phoenix DIN Rail Mounting Relay PLC-RPT- 60DC/21-21AU 2900341:
Spec | Value |
---|---|
Product type | Relay Module |
Nominal input voltage UN | 60 V DC |
Connection method | Push-in connection |
Mounting type | DIN rail mounting |
Phoenix DIN Rail Mounting Relay PLC-RPT- 60DC/21-21AU, 2900341 Technical Specifications:
Specification | Value |
---|---|
Product type | Relay Module |
Product family | PLC-INTERFACE |
Application | Universal |
Mechanical service life | 3x 107 cycles |
Insulation | Basic insulation |
Overvoltage category | III |
Pollution degree | 3 |
Maximum power dissipation for nominal condition | 0.6 W |
Test voltage (Winding/contact) | - |
Test voltage (Changeover contact/changeover contact) | - |
Rated surge voltage | 6 kV |
Nominal input voltage UN | 60 V DC |
Input voltage range | 51 V DC ... 84 V DC (20 °C) |
Drive and function | monostable |
Drive (polarity) | polarized |
Typical input current at UN | 10 mA |
Typical response time | 8 ms |
Typical release time | 10 ms |
Protective circuit | Reverse polarity protection; Polarity protection diode |
Operating voltage display | Yellow LED |
Contact switching type | 2 changeover contacts |
Type of switch contact | Single contact |
Contact material | AgNi, hard gold-plated |
Maximum switching voltage | 250 V AC/DC |
Limiting continuous current | 6 A |
Maximum inrush current | 15 A (300 ms) |
Min. switching current | 10 mA |
Interrupting rating (ohmic load) max. | 140 W (at 24 V DC) |
Switching capacity | 2 A (at 24 V, DC13) |
Connection method | Push-in connection |
Stripping length | 10 mm |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
Conductor cross section flexible | 0.14 mm² ... 2.5 mm² |
Conductor cross section AWG | 26 ... 14 |
Tightening torque | - |
Width | 14 mm |
Height | 80 mm |
depth | 94 mm |
Color | gray (RAL 7042) |
Flammability rating according to UL 94 | V0 (Housing) |
Degree of protection (Relay) | RT III (Relay) |
Degree of protection (Relay base) | IP20 (Relay base) |
Ambient temperature (operation) | -40 °C ... 60 °C |
Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Temperature | D |
Humidity | A |
Vibration | B/C |
EMC | B |
Enclosure | Required protection according to the Rules shall be provided upon installation on board |
Low Voltage Directive | Conformance with Low Voltage Directive |
Electromagnetic compatibility | Conformance with EMC directive |
Standards/regulations | IEC 60947-5-1 |
Mounting Type | DIN rail mounting |
Mounting position | any |
Contact Connection type | - |
Output fuse | - |
Degree of protection (Installation location) | - |
Reach Us by Email for Phoenix DIN Rail Mounting Relay PLC-RPT- 60DC/21-21AU part no: 2900341 at Discounted Rates. Key Technical Features of PLC-RPT- 60DC/21-21AU, 2900341 are Relay Module type and PLC-INTERFACE Product family a versatile solution for Universal applications. This relay module features a mechanical service life of 3x 107 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.6 W, it operates efficiently at a nominal input voltage of 60 V DC, within an input voltage range of 51 V DC ... 84 V DC (20 °C). The module has a typical input current of 10 mA at UN, with a response time of 8 ms and a release time of 10 ms. It is equipped with a Reverse polarity protection; Polarity protection diode for protection and includes 2 changeover contacts made from Push-in connection Connection method. Navigate Your Needs with a Quote for your requirement of Phoenix DIN Rail Mounting Relay. Our pricing and support are unrivaled, especially when compared to other Competitors.
