PLC-RPT- 24DC/21-21/MS: 2910519 - Phoenix Contact 24 VDC Relay
Technical Specifications of Phoenix Contact 24 VDC Relay PLC-RPT- 24DC/21-21/MS 2910519:
Spec | Value |
---|---|
Product type | Relay Module |
Nominal input voltage UN | 24 V DC |
Connection method | Push-in connection |
Mounting type | DIN rail mounting |
Phoenix Contact 24 VDC Relay PLC-RPT- 24DC/21-21/MS, 2910519 Technical Specifications:
Specification | Value |
---|---|
Product type | Relay Module |
Product family | PLC-INTERFACE |
Application | Palm switch |
Mechanical service life | 5x 106 cycles |
Insulation | Safe isolation, reinforced insulation |
Overvoltage category | III |
Pollution degree | 2 |
Maximum power dissipation for nominal condition | 0.44 W |
Test voltage (Winding/contact) | 4 kVrms (50 Hz, 1 min.) |
Test voltage (Changeover contact/changeover contact) | 2.5 kVrms (50 Hz, 1 min.) |
Rated surge voltage | 6 kV |
Nominal input voltage UN | 24 V DC |
Input voltage range | 20.2 V DC ... 33.6 V DC (20 °C) |
Drive and function | monostable |
Drive (polarity) | polarized |
Typical input current at UN | 18 mA |
Typical response time | 10 ms |
Typical release time | 10 ms |
Protective circuit | Surge protection; Freewheeling diode |
Operating voltage display | Yellow LED |
Contact switching type | 2 changeover contacts |
Type of switch contact | Single contact |
Contact material | AgNi |
Maximum switching voltage | 250 V AC/DC (The separating plate PLC-ATP should be installed for voltages larger than 250 V (L1, L2, L3) between identical terminal blocks in adjacent modules. Potential bridging is then carried out with FBST 8-PLC... or ...FBST 500...) |
Limiting continuous current | 6 A |
Maximum inrush current | 12 A (20 ms) |
Min. switching current | 10 mA (12 V) |
Interrupting rating (ohmic load) max. | 192 W (24 V DC) |
Switching capacity | 1 A (24 V, DC13) |
Connection method | Push-in connection |
Stripping length | 10 mm |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
Conductor cross section flexible | 0.14 mm² ... 2.5 mm² |
Conductor cross section AWG | 26 ... 14 |
Tightening torque | - |
Width | 14 mm |
Height | 80 mm |
depth | 104 mm |
Color | gray (RAL 7042) |
Flammability rating according to UL 94 | V0 (Housing) |
Degree of protection (Relay) | RT II |
Degree of protection (Relay base) | IP20 |
Ambient temperature (operation) | -40 °C ... 60 °C |
Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Temperature | D |
Humidity | A |
Vibration | B/C |
EMC | B |
Enclosure | Required protection according to the Rules shall be provided upon installation on board |
Low Voltage Directive | Conformance with Low Voltage Directive |
Electromagnetic compatibility | Conformance with EMC directive |
Standards/regulations | IEC 60947-5-1 |
Mounting Type | DIN rail mounting |
Mounting position | any |
Contact Connection type | - |
Output fuse | - |
Degree of protection (Installation location) | ≥ IP54 |
Mail Us for your needs in Phoenix Contact 24 VDC Relay PLC-RPT- 24DC/21-21/MS part no: 2910519 with budget-friendly prices. The Main Technical Parameters of PLC-RPT- 24DC/21-21/MS, 2910519 inludce Relay Module type and PLC-INTERFACE Product family a versatile solution for Palm switch applications. This relay module features a mechanical service life of 5x 106 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.44 W, it operates efficiently at a nominal input voltage of 24 V DC, within an input voltage range of 20.2 V DC ... 33.6 V DC (20 °C). The module has a typical input current of 18 mA at UN, with a response time of 10 ms and a release time of 10 ms. It is equipped with a Surge protection; Freewheeling diode for protection and includes 2 changeover contacts made from Push-in connection Connection method. Customize Your Experience with a Quote for your requirement of Phoenix Contact 24 VDC Relay. Experience the difference with our competitive pricing and superior support over other Suppliers.
