HCC 4-F , 1600001, Phoenix High Current Terminal Block Technical Specifications
Specification
Value
Product type
High current terminal block
Number of positions
10
Number of connections
10
Number of rows
1
Potentials
10
Overvoltage category
III
Degree of pollution
3
Rated surge voltage
6 kV
Maximum power dissipation for nominal condition
1.02 W
Number of connections per level
10
Nominal cross section
4 mm²
Screw thread
M3
Tightening torque
0.5 ... 0.6 Nm
Stripping length
7 mm
Internal cylindrical gage
A4
Connection in acc. with standard
IEC 61984
Conductor cross section rigid
0.2 mm² ... 4 mm²
Nominal current
25 A
Maximum load current
25 A (with 4 mm² conductor cross section)
Nominal voltage
500 V
Width
92 mm
Height
31.5 mm
Depth
18 mm
Color
gray (RAL 7042)
Flammability rating according to UL 94
V2
Insulating material group
I
Insulating material
PA
Static insulating material application in cold
-40 °C
Relative insulation material temperature index (Elec., UL 746 B)
125 °C
Test voltage setpoint
-
Open side panel
No
DIN rail/fixing support
-
Test force setpoint
-
Rotation speed
-
Revolutions
-
Conductor cross section/weight
-
Time of exposure
-
Frequency
-
ASD level
-
Acceleration
-
Test duration per axis
-
Test directions
-
Pulse shape
-
Shock duration
-
Number of shocks per direction
-
Ambient temperature (operation)
-60 °C ... 110 °C (Operating temperature range incl. self-heating; for max. short-term operating temperature, see RTI Elec.)
Ambient temperature (storage/transport)
-25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Ambient temperature (assembly)
-5 °C ... 70 °C
Ambient temperature (actuation)
-5 °C ... 70 °C
Permissible humidity (operation)
20 % ... 90 %
