FL SWITCH 2308 PN: 1009220 - Phoenix 8 RJ45 ports Ethernet Switch
Technical Specifications of Phoenix Contact 8 RJ45 ports Ethernet Switch FL SWITCH 2308 PN 1009220:
| Spec | Value |
|---|---|
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| No. of channels | 8 (RJ45 ports) |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (link/activity and speed), PROFINET status LEDs (BF, SF) |
FL SWITCH 2308 PN: 1009220 - Phoenix 8 RJ45 ports Ethernet Switch
| Specification | Value |
|---|---|
| Width | 45 mm |
| Height | 130 mm |
| Depth | 119 mm |
| Housing material | Polycarbonate fiber reinforced |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 10/100/1000 Mbps |
| Transmission length | 100 m (per segment) |
| Signal LEDs | Data receive, link status |
| No. of channels | 8 (RJ45 ports) |
| Product type | Switch |
| MTTF | 381.77 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) |
| Article revision | 7 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 12 V DC ... 57 V DC |
| Power supply connection | via COMBICON, max. conductor cross section 1.5 mm² |
| Max. current consumption | 1.4 A (US = Min, Tamb = Max, DOI = Max) |
| Typical current consumption | 280 mA (at US = 24 V DC and 25 °C ambient temperature) |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 10 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-3 |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (link/activity and speed), PROFINET status LEDs (BF, SF) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Obtain a Quote for Phoenix Contact 8 RJ45 ports Ethernet Switch FL SWITCH 2308 PN part no: 1009220 at economical prices. Specifications Overview for FL SWITCH 2308 PN, 1009220 reveals Polycarbonate fiber reinforced housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard DIN rail mounting making it ideal for streamlined setup in control panels. The connection method is via reliable Push-in spring connection, providing secure and stable connectivity. With a transmission speed of 10/100/1000 Mbps it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to 100 m (per segment) making it versatile for various industrial settings. It features 8 (RJ45 ports). Take the First Step with a Quote for your requirement of Phoenix Contact 8 RJ45 ports Ethernet Switch. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
