Pepperl Fuchs UB400-F77-E2-V31 Ultrasonic Sensor
The Pepperl Fuchs UB400-F77-E2-V31 Ultrasonic Sensor offers a Rectangular design, 25 ... 400 mm sensing range, 1 switch output PNP, NO output, and M8 x 1 connector , 4-pin connection. Manufactured by Pepperl Fuchs under the P&F Ultrasonic Sensor category, this model belongs to the diffuse reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Ultrasonic Sensor |
| Model Number | UB400-F77-E2-V31 |
Pepperl Fuchs UB400-F77-E2-V31 Ultrasonic Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type of Sensing | Diffuse Reflective |
| Design | Rectangular |
| Sensing range | 25 ... 400 mm |
| Adjustment range | 40 ... 400 mm |
| Dead band | 0 ... 25 mm |
| Standard target plate | 20 mm x 20 mm |
| Transducer frequency | approx. 300 kHz |
| Response delay | ≤ 75 ms |
| LED green | - |
| LED yellow 1 | switching state and flashing: Teach-In |
| LED yellow 2 | - |
| LED red | - |
| Operating voltage | 20 ... 30 V DC , ripple 10 %SS ; 12 ... 20 V DC sensitivity reduced to 90 % |
| Output type | 1 switch output PNP, NO |
| Default setting | - |
| Repeat accuracy | ± 1 mm |
| Switching frequency | 5 Hz |
| Range hysteresis | typ. 4 mm |
| Temperature influence | 0.17 %/K |
| Standards | EN IEC 60947-5-2:2020 IEC 60947-5-2:2019 |
| UL approval | cULus Listed, Class 2 Power Source |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Connection type | M8 x 1 connector , 4-pin |
| Degree of protection | IP67 |
| Material Housing | Polycarbonate |
IndMALL Offers P&F PNP NO Diffuse Reflective Sensor UB400-F77-E2-V31 at economical Choices. Product Tech Specs of UB400-F77-E2-V31 include Diffuse Reflective, Rectangular design with a sensing range of 25 ... 400 mm and an adjustment range of 40 ... 400 mm. It has a dead band of 0 ... 25 mm and uses a standard target plate of 20 mm x 20 mm. The transducer frequency is approximate approx. 300 kHz, and the response delay of ≤ 75 ms. Operating at 20 ... 30 V DC , ripple 10 %SS ; 12 ... 20 V DC sensitivity reduced to 90 %, the sensor includes 1 switch output PNP, NO. It offers repeat accuracy of ± 1 mm, a switching frequency of 5 Hz, range hysteresis of typ. 4 mm, and a temperature influence of 0.17 %/K. The sensor operates in ambient temperatures from -25 ... 70 °C (-13 ... 158 °F) and can be stored in temperatures from -40 ... 85 °C (-40 ... 185 °F). It feature M8 x 1 connector , 4-pin, an IP67 protection rating, and an Polycarbonate housing. Now's the Time to Secure a Quote for your requirement of P&F PNP NO Diffuse Reflective Sensor. Trust in our superior pricing and more dedicated support over other Distributors.
