Pepperl Fuchs UB100-F77-E2-V31 Ultrasonic Sensor
The Pepperl Fuchs UB100-F77-E2-V31 Ultrasonic Sensor offers a Rectangular design, 10 ... 100 mm sensing range, 1 switch output PNP, NO output, and M8 x 1 connector , 4-pin connection. Manufactured by Pepperl Fuchs under the P&F Ultrasonic Sensor category, this model belongs to the diffuse reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Ultrasonic Sensor |
| Model Number | UB100-F77-E2-V31 |
Pepperl Fuchs UB100-F77-E2-V31 Ultrasonic Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type of Sensing | Diffuse Reflective |
| Design | Rectangular |
| Sensing range | 10 ... 100 mm |
| Adjustment range | 30 ... 100 mm |
| Dead band | 0 ... 10 mm |
| Standard target plate | 20 mm x 20 mm |
| Transducer frequency | approx. 400 kHz |
| Response delay | ≤ 50 ms |
| LED green | - |
| LED yellow 1 | switching state and flashing: Teach-In |
| LED yellow 2 | - |
| LED red | - |
| Operating voltage | 20 ... 30 V DC , ripple 10 %SS ; 12 ... 20 V DC sensitivity reduced to 90 % |
| Output type | 1 switch output PNP, NO |
| Default setting | - |
| Repeat accuracy | ± 1 mm |
| Switching frequency | 10 Hz |
| Range hysteresis | typ. 2.5 mm |
| Temperature influence | 0.17 %/K |
| Standards | EN IEC 60947-5-2:2020 IEC 60947-5-2:2019 |
| UL approval | cULus Listed, Class 2 Power Source |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient temperature | -10 ... 50 °C (14 ... 122 °F) |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Connection type | M8 x 1 connector , 4-pin |
| Degree of protection | IP67 |
| Material Housing | Polycarbonate |
Give Us a Call for P&F PNP NO Ultrasonic Sensor UB100-F77-E2-V31 at the lowest pricing. In-depth Technical Analysis of UB100-F77-E2-V31 feature Diffuse Reflective, Rectangular design with a sensing range of 10 ... 100 mm and an adjustment range of 30 ... 100 mm. It has a dead band of 0 ... 10 mm and uses a standard target plate of 20 mm x 20 mm. The transducer frequency is approximate approx. 400 kHz, and the response delay of ≤ 50 ms. Operating at 20 ... 30 V DC , ripple 10 %SS ; 12 ... 20 V DC sensitivity reduced to 90 %, the sensor includes 1 switch output PNP, NO with default -. It offers repeat accuracy of ± 1 mm, a switching frequency of 10 Hz, range hysteresis of typ. 2.5 mm, and a temperature influence of 0.17 %/K. The sensor operates in ambient temperatures from -10 ... 50 °C (14 ... 122 °F) and can be stored in temperatures from -40 ... 85 °C (-40 ... 185 °F). It feature M8 x 1 connector , 4-pin, an IP67 protection rating, and an Polycarbonate housing. Elevate Your Project with a Quote for your requirement of P&F PNP NO Ultrasonic Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
