Home Products Photoelectric Sensor Pepperl Fuchs RLK31-54/25/31/115 SET2 Pepperl Fuchs RLK31-54/25/31/115 SET2 Photoelectric Sensor The Pepperl Fuchs RLK31-54/25/31/115 SET2 Photoelectric Sensor offers a 0 ... 9000 mm detection range, LED light source, and 2 m fixed cable connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
Brand Pepperl Fuchs Product Type Photoelectric Sensor Model Number RLK31-54/25/31/115 SET2
Pepperl Fuchs RLK31-54/25/31/115 SET2 Photoelectric Sensor – Technical Specifications Specification Value Effective detection range 0 ... 9000 mm Reflector distance 20 ... 9000 mm Threshold detection range 12 m Reference target reflector C110-2 Light source LED Light type modulated visible red light , 630 nm Polarization filter - Diameter of the light spot approx. 200 mm at a distance of 6 m Opening angle 3 ° Optical face - Control elements - Operating voltage 24 ... 240 V AC12 ... 240 V DC Ripple - No-load supply current ≤ 40 mA Switching type light-on Signal output Relay, 1 alternator Switching voltage max. 240 V AC Switching current max. 3 A Voltage drop - Switching frequency 20 Hz Response time ≤ 25 ms Ambient temperature -25 ... 55 °C (-13 ... 131 °F) Storage temperature -40 ... 70 °C (-40 ... 158 °F) Degree of protection IP67 Connection 2 m fixed cable Mass 154 g Cable length -
