P&F Triangulation Sensor OBT350-R100-2EP-IO-V31
Challaturu offers the P&F OBT350-R100-2EP-IO-V31 photoelectric switch, which is a Triangulation sensor that provides a PNP output and a detection range of 0 to 5m to fulfill your requirements.
OBT350-R100-2EP-IO-V31 Technical Specifications:
| Detection range | 5 … 350 mm | |
| Detection range min. | 5 … 25 mm | |
| Detection range max. | 5 … 350 mm | |
| Adjustment range | 25 … 350 mm | |
| Reference target | standard white, 100 mm x 100 mm | |
| Light source | LED | |
| Light type | modulated visible red light | |
| Operating voltage | 10 … 30 V DC | |
| Switching type | The switching type of the sensor is adjustable. The default setting is: C/Q – Pin4: NPN normally open / light-on, PNP normally closed / dark-on, IO-Link /Q – Pin2: NPN normally closed / dark-on, PNP normally open / light-on |
|
| Switching voltage | max. 30 V DC | |
| Signal Ouput | 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected | |
| Switching current | max. 100 mA , resistive load | |
| Switching frequency | 500 Hz | |
| Response time | 1 ms | |
| Ambient temperature | -40 … 60 °C (-40 … 140 °F) | |
| Degree of protection | IP67 / IP69 / IP69K | |
| Connection | M8 x 1 connector, 4-pin | |
Product Documentation: OBT350-R100-2EP-IO-V31
Here is the main technical specification of Pepperl Fuchs Photoelectric Sensor OBT350-R100-2EP-IO-V31: laser diode, Detection range: 5 to 350 mm, PNP, Red, M8 x 1 connector type.
If you want to know all ranges of Pepperl Fuchs photo sensors you can check.
Related Products: OBT350-R100-2EP-IO-V31
ML100-8-1000-RT/103/115
Type: Diffuse photoelectric sensor, Detection range: 0 … 1000 mm, Switching frequency: 1000 Hz, Housing: 11 mm x 31 mm x 20 mm, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector Response time: 0.5 ms, Connection: 2 m fixed cable, Housing: PC (Polycarbonate), Degree of protection: IP67, Cable length: 2 m.
ML100-55/103/115
Type: Reflective Photo Sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Switching frequency: 1000 Hz, Housing dimensions (WxHxD): 11 mm x 31 mm x 20 mm, Switching type: Adjustable (default: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Response time: 0.5 ms, Operating voltage: 10 … 30 V DC, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable length: 2 m.
GLV18-55/115/120
Type: Reflective Photo Sensor, Detection range: 0 … 4 m, Light source: LED (modulated visible red light, 640 nm), Housing (WxHxD): M18 threaded housing design, Response time: ≤ 1 ms, Switching type: Light/dark-on, Signal output: 2 PNP, complementary, short-circuit protected, open collectors, Switching frequency: 500 Hz, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: Plastic, Operating voltage: 10 … 30 V DC, Cable Length: 2 m.
OBT500-18GM60-E5
Type: Diffuse Type PhotoSensor, Detection range: 0 … 500 mm, Light source: IRED (Infrared), 880 nm, Switching frequency: 500 Hz, Operating voltage: 10 … 30 V DC, Switching type: Light/dark-on, electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Response time: 1 ms, Connection: 2 m fixed cable, Housing material: Brass, nickel-plated, Degree of protection: IP67, Cable length: 2 m.
OBT200-18GM60-E5-V1
Type: Diffuse mode Photosensor, Detection range: 0 … 200 mm, Light source: IRED (Infrared Emitting Diode), 880 nm, Operating voltage: 10 … 30 V DC, class 2, Switching type: Light/dark-on, electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching voltage: Max. 30 V DC, Housing (WxHxD): Not specified, Switching frequency: 500 Hz, Response time: 1 ms, Degree of protection: IP67, Connection: 4-pin, M12 x 1 connector, Housing material: Brass, nickel-plated.
