Home Products Proximity Sensor Pepperl Fuchs NBN2-F58S-100S3-E8-V1 Pepperl Fuchs NBN2-F58S-100S3-E8-V1 Proximity Sensor The Pepperl Fuchs NBN2-F58S-100S3-E8-V1 Proximity Sensor offers a 2 mm operating distance, 4-wire, PNP, 2 x normally open (NO), output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Proximity Sensor Model Number NBN2-F58S-100S3-E8-V1
Pepperl Fuchs NBN2-F58S-100S3-E8-V1 Proximity Sensor – Technical Specifications Specification Value Switching function 2 x normally open (NO) Output type 4-wire, PNP Rated operating distance 2 mm Installation non-flush Output polarity DC Assured operating distance 0 ... 1.62 mm Operating voltage 10 ... 30 V Switching frequency 0 ... 100 Hz Reverse polarity protection reverse polarity protected Short-circuit protection pulsing Switching state indicator Switching state "closed" = LED red (S2)switching state "open" = LED yellow (S1) Ambient temperature 0 ... 50 °C (32 ... 122 °F) Storage temperature -40 ... 85 °C (-40 ... 185 °F) Connection type Connector plug M12 x 1 , 4-pin Housing material Amplifier: PA66 Badamid,Oscillators: PBT Degree of protection IP65
