Pepperl Fuchs Inductive Sensor NBB15-30GM50-A2-V1
NBB15-30GM50-A2-V1 Technical Specifications:
Challaturu provides the Pepperl+Fuchs inductive Proximity Sensor NBB15-30GM50-A2-V1 that satisfies your industrial requirements with an M30, Flush type, M12 Connector, Complementary, 4-wire output, and a sensing distance of 15mm.
| Sensor Head | M30 | |
| Switching function | Complementary | |
| Output type | PNP | |
| Rated operating distance | 15 mm | |
| Installation | Flush | |
| Output polarity | DC | |
| Assured operating distance | 0 … 12.15 mm | |
| Output type | 4-wire | |
| Operating voltage | 5 … 36 V | |
| Switching frequency | 0 … 550 Hz | |
| Ambient temperature | -40 … 85 °C (-40 … 185 °F) | |
| Connection type | Connector plug | |
| Housing material | brass, white bronze coated | |
| Sensing face | PBT, Green | |
| Degree of protection | IP68 | |
| Connector Threading | M12 x 1 | |
| Number of Pins | 4 | |
Product Documentation: NBB15-30GM50-A2-V1
Related Products: NBB15-30GM50-A2-V1
NBB15-30GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM50-E2
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM50-E2-C-V1
Inductive Proximity Sensor Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 10 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1, Operating voltage: 10 … 30 V DC, Housing material: Brass with PTFE coating, Degree of protection: IP67.
NBB10-30GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
IndMALL Automation offers inductive Sensors and capacitive proximity sensors at Comprehensive prices. The Pepperl Fuchs NBB15-30GM50-A2-V1 Proximity Switch Head has an M30 connection type with a complementary switching function and a PNP output type. It has a rated operating distance of 15 mm and is designed for flush installation with a DC output polarity.
The assured operating distance is 0 to 12.15 mm. The output type is 4-wire and it operates within a voltage range of 5 to 36 V with a switching frequency range of 0 to 550 Hz. It can operate within a wide temperature range of -40 to 85 °C (-40 to 185 °F).
The connection type is a connector plug and the housing material is made of brass with a white bronze coating while the sensing face is made of PBT in green color. It has a degree of protection of IP68 and the connector threading is M12 x 1 with 4 pins.
