Home Products Proximity Sensor Pepperl Fuchs NBB10-30GM50-WO-T-Y802858 Pepperl Fuchs NBB10-30GM50-WO-T-Y802858 Proximity Sensor The Pepperl Fuchs NBB10-30GM50-WO-T-Y802858 Proximity Sensor offers a 10 mm operating distance, 2-wire, -, output, and flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Proximity Sensor Model Number NBB10-30GM50-WO-T-Y802858
Pepperl Fuchs NBB10-30GM50-WO-T-Y802858 Proximity Sensor β Technical Specifications Specification Value Switching function - Output type 2-wire Rated operating distance 10 mm Installation flush Assured operating distance 0 ... 8.1 mm Switching frequency 0 ... 20 Hz Hysteresis 1 ... 10 % typ. 5 % Reverse polarity protection yes Short-circuit protection no Switching state indicator LED, yellow Ambient temperature -25 ... 100 Β°C (-13 ... 212 Β°F) Connection type cable Housing material brass, nickel-plated Sensing face PBT Degree of protection IP67
