Omron S8VS-09024S Power Supply
The Omron S8VS-09024S Power Supply provides a regulated 24 VDC output at 3.75 A from a 90 W switch mode power supply configuration for industrial automation equipment. The unit accepts 100 to 240 VAC at 50/60 Hz and mounts on a DIN rail inside the electrical cabinet. Screw terminals provide the interface for connecting the input supply and outgoing DC circuit. This combination of output voltage and current supports compatible 24 VDC loads used across control panels and automated machine systems. The S8VS-09024S identifies this configuration as part of the S8VS Series. Within the product hierarchy, it also belongs to the 90W industrial SMPS range associated with Omron factory automation equipment.
| Brand | Omron |
| Product | Power Supply |
| Model Number | S8VS-09024S |
Omron S8VS-09024S Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 90 W |
| Output voltage | 24 VDC |
| Rated output current | 3.75 A |
| Terminal type | Screw Terminal |
| Mounting method | DIN rail |
| Connection | Terminal blocks |
| Efficiency | 83% typ. (at 100 VAC input) 84% typ. (at 200 VAC input) |
| Rated input voltage | 100 to 240 VAC |
| Rated input current | 2.3 A max., 1.9 A typ. (at 100 VAC input) 1.4 A max., 1 A typ. (at 200 VAC input) |
| Input Leakage current | 0.5 mA max. (at 100 VAC input) 1.0 mA max. (at 200 VAC input) |
| Input Frequency | 50/60Hz |
| Output indicator | Yes (color: green) |
| Output voltage variable range | -10 to +15% With V.ADJ |
| Start-up time | 460 ms typ. (at 100 VAC input) 300 ms typ. (at 200 VAC input) |
| Hold time | 28 ms typ. (at 100 VAC input) 132 ms typ. (at 200 VAC input) |
| Vibration resistance | 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | -10 to 60 ? |
| Ambient temperature (Storage) | -25 to 65 ? |
| Ambient humidity (OperatingStorage) | 25 to 85% |
| Cooling fan | No |
| Weight | 490 g max. |
The Omron S8VS-09024S is frequently evaluated with other models in the Omron Switch Mode Power Supply group, as these SMPS units share similar behaviour in thermal response, wiring layout, load handling, and rated input characteristics. Engineers often compare related models such as Omron S8VS-12024B (120 W, 24 VDC, 100 to 240 VAC, 5 A, DIN rail), Omron S8VS-09024AP (90 W, 24 VDC, 100 to 240 VAC, 3.75 A, DIN rail), and Omron S8VS-09024BE (90 W, 24 VDC, 100 to 240 VAC, 3.75 A, DIN rail) when designing power rails for automation cabinets, motion drives, PLC racks, or distributed I/O stations. Analysing differences in power rating, output voltage behaviour, mounting format, rated input voltage, and continuous output current helps ensure voltage stability under diverse machine loads. The S8VS-09024S integrates smoothly into conveyors, dosing modules, electrical frames, and industrial panels where a dependable Omron SMPS Power Supply is required.
