Omron NX-ID6142-5 Machine Automation Controller
The Omron NX-ID6142-5 Machine Automation Controller Digital Input Unit provides 32 channels for high-density signal acquisition using either NPN or PNP input configurations. It operates at a rated 24 VDC and supports Switching Synchronous I/O refreshing and Free-Run refreshing for flexible machine-control integration. Response times of up to 20 μs ON and 400 μs OFF enable rapid detection of input-state changes in automated equipment. A 30 mm wide MIL connector interface supports efficient wiring of multiple field signals within compact control architectures. The NX-ID6142-5 combines high-density inputs with flexible wiring within the high-speed PLC input range supporting Omron industrial automation.
| Brand | Omron |
| Product Type | Machine Automation Controllers |
| Model Number | NX-ID6142-5 |
Omron NX-ID6142-5 Machine Automation Controller - Technical Specifications
| Specification | Value |
|---|---|
| Product name | DC Input Unit |
| I/O system | NX I/O Bus |
| Type of module | Digital I/O |
| Number of digital inputs | 32 |
| Digital input type | PNP/NPN |
| Rated input voltage | 24 VDC |
| Digital output type | None |
| Connection method | 1-wire |
| Signal processing | Free running, Standard speed, Synchronous |
| I/O connection type | MIL (plug not included) |
| Number of I/O connectors | 1 |
| ON response time | 20 μs max. |
| OFF response time | 400 μs max |
| Degree of protection (IP) | IP20 |
| Product Weight (unpacked) | 135 g |
Mail Us for your needs in Omron PLC MIL40 Connector NX-ID6142-5 with budget-friendly prices. The Main Technical Parameters of NX-ID6142-5 include 32 points with internal I/O common For both NPN/PNP and operates on a rated input voltage of 24 VDC. It supports both Switching Synchronous I/O refreshing and Free-Run refreshing methods, with an ON/OFF response time of 20 μs max./400 μs max. The unit's dimensions are 72 × 100 × 90 mm (W×H×D), and it requires a power supply voltage of 24 VDC (20.4 to 28.8 VDC) with a maximum power consumption of 5.80 W max. It also meets noise immunity standards of 2 kV on power supply line (Conforms to IEC 61000-4-4.) and has a pollution degree of 2 or less: Meets IEC 61010-2-201. The ambient operating temperature ranges from 0 to 55°C, with humidity from 10% to 95% (with no condensation), and storage temperatures from -25 to 70°C (excluding battery).Customize Your Experience with a Quote for your requirement of Omron PLC MIL40 Connector. Experience the difference with our competitive pricing and superior support over other Suppliers.
