H7ER-NV1-H: Omron 5-Digit High-Precision Tachometer
Technical Specifications of Omron 5-Digit High-Precision Tachometer H7ER-NV1-H:
| Spec | Value |
|---|---|
| Function | Tachometer |
| Preset Stages | 1 kHz/10 kHz (selectable) |
| Input Signal | Count input |
| Input Method | Voltage input |
Omron 5-Digit High-Precision Tachometer H7ER-NV1-H Technical Specifications:
| Specification | Value |
|---|---|
| Function | Tachometer |
| Preset stages | 1 kHz/10 kHz (selectable) |
| Tachometer Max. counting speed | 0.5 ms(1 kHz) 0.05 ms(10 kHz) |
| Tachometer Max Display speed | 1000.0 s-1(rps) (When encoder resolution of 10 pulse/rev is used.) 1000 min-1(rpm) (When encoder resolution of 600 pulse/rev is used.) 10000 min-1(rpm) (When encoder resolution of 60 pulse/rev is used.) |
| Input signal | Count input |
| Input method | Voltage input |
| No-voltage input (No-contact input）/ Voltage input | Voltage input: Hight level: 4.5 to 30 VDC Low level: 0 to 2 VDC (Input resistance Approx. 4.7 kΩ) |
| Display method | Backlit transmissive LCD |
| Display Digits | 5 digit |
| Display Character height | 8.6 mm (Black) |
| Display Zero suppression | Equipped |
| Ambient temperature (Operating) | -10 to 55 ℃ (with no freezing or condensation) |
| Ambient temperature (Storage) | -25 to 65 ℃ (with no freezing or condensation) |
IndMALL Automation Dealing offers Omron 5-Digit High-Precision Tachometer, H7ER-NV1-H at unbeatable prices. The Main Technical Parameters of H7ER-NV1-H includes Voltage input, Count input, Voltage input: Hight level: 4.5 to 30 VDC
Low level: 0 to 2 VDC (Input resistance Approx. 4.7 kΩ), Backlit transmissive LCD. Additionally, it provides 1000.0 s-1(rps) (When encoder resolution of 10 pulse/rev is used.)
1000 min-1(rpm) (When encoder resolution of 600 pulse/rev is used.)
10000 min-1(rpm) (When encoder resolution of 60 pulse/rev is used.), 0.5 ms(1 kHz)
0.05 ms(10 kHz), Tachometer. Take the First Step with a Quote for your requirement of Omron 5-Digit High-Precision Tachometer. Choose us for unparalleled pricing and support over other Dealers & Distributors.
