E6C3-AN1E 256P/R 2M: Omron Voltage Output Rotary Encoder

Technical Specifications of Omron Voltage Output Rotary Encoder E6C3-AN1E 256P/R 2M:

SpecValue
Encoding MethodAbsolute Shaft model
Resolution256 P/R
Output CodeBinary code
Control OutputVoltage output
Connection MethodPre-wired models (Cable length: 2 m)

Omron Voltage Output Rotary Encoder E6C3-AN1E 256P/R 2M Technical Specifications:

SpecificationValue
Encoding MethodAbsolute Shaft model
Resolution256 P/R
Output codeBinary code
Control outputVoltage output
Connection methodPre-wired models (Cable length: 2 m)
Diameter50 mm dia.
Power supply voltage5 VDC±5%
Current consumption70 mA max.
Inrush currentApprox. 6 A (0.8 ms)
LogicPositive logic (high = 1, low = 0)
Ambient temperatureOperating: -10 to 70 ℃ (with no icing) Storage: -25 to 85 ℃ (with no icing)
Degree of protectionIEC: IP65
MaterialCase: Aluminum
Weight--
AccessoriesInstruction manual
The Omron E6C3-AN1E 256P/R 2M Voltage Output Rotary Encoder is a precise and dependable solution for industrial automation. This absolute shaft model offers a resolution of 256 pulses per revolution (P/R) with binary coding for accurate position detection. It features a 50 mm diameter and a 2-meter pre-wired cable, ensuring easy installation in various systems. With a maximum current consumption of 70 mA and positive logic output (high = 1, low = 0), this encoder delivers reliable performance for demanding applications. The E6C3-AN1E 256P/R 2M combines advanced functionality with affordability, making it a preferred choice in motion control setups. IndMALL Automation provides competitive pricing and excellent support for the Omron Voltage Output Rotary Encoder, ensuring seamless integration and performance in automation systems.
