E6C3-AG5C-C 360P/R 1M: Omron Enhanced Precision Encoder

Technical Specifications of Omron Enhanced Precision Encoder E6C3-AG5C-C 360P/R 1M:

SpecValue
Encoding MethodAbsolute Shaft model
Resolution360 P/R
Output CodeGray code
Control OutputNPN open collector
Connection MethodPre-wired models (Cable length: 1 m)

Omron Enhanced Precision Encoder E6C3-AG5C-C 360P/R 1M Technical Specifications:

SpecificationValue
Encoding MethodAbsolute Shaft model
Resolution360 P/R
Output codeGray code
Control outputNPN open collector
Connection methodPre-wired models (Cable length: 1 m)
Diameter50 mm dia.
Power supply voltage12 to 24 VDC (-10% to +15%) Ripple (p-p) 5% max.
Current consumption70 mA max.
Inrush currentApprox. 6 A (0.8 ms)
LogicNegative logic (high = 0, low = 1)
Ambient temperatureOperating: -10 to 70 ℃ (with no icing) Storage: -25 to 85 ℃ (with no icing)
Degree of protectionIEC: IP65
MaterialCase: Aluminum
WeightPackage: Approx. 300 g
AccessoriesInstruction manual
The Omron Enhanced Precision Encoder E6C3-AG5C-C 360P/R 1M is a reliable solution for high-accuracy applications. This absolute shaft encoder provides a resolution of 360 pulses per revolution (P/R), making it ideal for precise motion and position tracking. Featuring a compact 50 mm diameter and a 1-meter pre-wired cable, it ensures easy integration into various industrial setups. With a power supply of 5 to 12 VDC, it operates efficiently, consuming a maximum of 70 mA. The encoder uses Gray code output and an NPN open collector, offering compatibility and reliable performance with negative logic (high = 0, low = 1). Whether you’re searching for an E6C3-AG5C-C 360P/R 1M or a trusted Omron Enhanced Precision Encoder, IndMALL Automation provides competitive prices and exceptional support to meet your automation needs.
