Omron E5CN-HC2M-500 Digital Temperature Controller

The Omron E5CN-HC2M-500 Temperature Controller is an advanced 1/16 DIN digital controller with a 48 × 48 × 78 mm body designed for industrial temperature regulation through a current output. Operating from 100 to 240 VAC at 50/60 Hz, it supports ON/OFF or 2-PID control with auto-tuning for different thermal process requirements. Its current output and two auxiliary outputs provide interfaces for the primary temperature control signal and additional process functions. Front-panel keys support digital setting, while an 11-segment display provides clear operating information and screw terminal blocks support panel wiring. The E5CN-HC2M-500 belongs to the E5CN Series within the current output temperature controller range from Omron process control products.

Brand	Omron
Product	Temperature Controllers
Model Number	E5CN-HC2M-500

Omron E5CN-HC2M-500 Temperature Controller - Technical Specifications

Specification	Value
Shape	1/16 DIN 48 × 48 × 78 (W × H × D)
Power supply voltage	100 to 240 VAC, 50/60 Hz
Operating voltage range/ Allowable voltage variable range	85 to 110% of the power supply voltage
Power consumption	100 to 240 VAC: 8.5 VA (max.) (E5CN-HR2 at 100 VAC: 3.0 VA) 24 VAC/VDC: 5.5 VA (24 VAC)/3.5 W (24 VDC) (max.) (E5CN-HR2D at 24 VAC: 2.7 VA)
Control method	ON/OFF or 2-PID control with auto-tuning
Input Type/Temperature input	Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PL II Platinum resistance thermometer: Pt100 or JPt100 Current input: 4 to 20 mA or 0 to 20 mA Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V
Control output 1	Current output
Number of total auxiliary output	2
Setting method	Digital setting using front panel keys
Indication method	11-segment digital display and individual indicators (7-segments displays also possible); Character height: PV: 11 mm, SV: 6.5 mm
Insulation resistance	20 MΩ min. (at 500 VDC)
Dielectric strength	2,300 VAC, 50 or 60 Hz for 1 min (between terminals with different charge)
Vibration resistance	Malfunction: 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y, and Z directions Destruction: 10 to 55 Hz, 0.75-mm single amplitude for 2 hrs each in X, Y, and Z directions
Shock resistance	Malfunction: 100 m/s2, 3 times each in X, Y, and Z directions Destruction: 300 m/s2, 3 times each in X, Y, and Z directions
Ambient temperature (Operating)	−10 to 55°C (with no condensation or icing), for 3-year warranty: −10 to 50°C
Ambient temperature (Storage)	−25 to 65°C (with no condensation or icing)
Ambient humidity (Operating)	25% to 85%
Degree of protection	Front panel: IP66, Rear case: IP20, Terminals: IP00
Case color	Black
Terminal type	Screw terminal blocks
Weight	Controller: Approx. 210 g, Adapter: Approx. 4 g × 2
