Omron E5CD-RX2A6M-002 Digital Temperature Controller

The Omron E5CD-RX2A6M-002 Temperature Controller integrates a relay control output and two auxiliary functions into a compact digital temperature controller. A single input point provides process temperature information, while 100 to 240 VAC at 50/60 Hz supplies the 48 × 48 mm controller. ON/OFF or 2-PID control with auto-tuning provides different methods for managing the connected thermal process. Its relay output and two auxiliary outputs connect the primary temperature switching action with supporting control functions. Front-panel keys support digital setting, while an 11-segment display presents operating information and screw terminal blocks provide the specified wiring arrangement. The E5CD-RX2A6M-002 forms part of the E5CD Series under the industrial relay temperature controller range from Omron control products.

Brand	Omron
Product	Temperature Controllers
Model Number	E5CD-RX2A6M-002

Omron E5CD-RX2A6M-002 Temperature Controller - Technical Specifications

Specification	Value
Shape	48 × 48 mm
Power supply voltage	100 to 240 VAC, 50/60 Hz
Operating voltage range/ Allowable voltage variable range	85% to 110% of rated supply voltage
Power consumption	6.5 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VAC or 2.3 W max. at 24 VDC
Control method	ON/OFF or 2-PID control with auto-tuning
Number of input points	1 point
Input Type/Temperature input	Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, PLII Platinum resistance thermometer: Pt100, JPt100 Infrared Thermosensor: 10 to 70 ℃, 60 to 120 ℃, 115 to 165 ℃, 140 to 260 ℃
Control output 1	Relay output
Control output 2	None
Number of total auxiliary output	2
Setting method	Digital setting using front panel keys
Indication method	11-segment digital display, individual indicators, and bar display
Insulation resistance	20 MΩ min. (at 500 VDC)
Dielectric strength	3,000 VAC, 50/60 Hz for 1 min between terminals of different charge
Vibration resistance	10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions
Shock resistance	300 m/s2, 3 times each in X, Y, and Z directions
Ambient temperature (Operating)	-10 to 55 ℃ (with no freezing or condensation) For 3-year warranty with standard mounting: -10 to 50 ℃ (with no freezing or condensation)
Ambient temperature (Storage)	−25 to 65°C (with no condensation or icing)
Ambient humidity (Operating)	25% to 85%
Degree of protection	IP66, Rear case: IP20, Terminals: IP00
Terminal type	Screw terminal blocks
Weight	Controller: Approx. 210 g, Adapter: Approx. 4 g × 2
