Omron E3Z-T82 2M Photoelectric Sensor

The Omron E3Z-T82 2M Photoelectric Sensor offers Through-beam, 30 m Sensing distance, PNP Output, Pre-wired 2 M cable, 12 to 24 VDC Power Supply Voltage. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron E3Z Series and includes an Emitter (E3Z-T82-L 2M) and Receiver (E3Z-T82-D 2M), it utilizing a Infrared LED (870 nm), Light-ON/Dark-ON selectable mode.

Omron E3Z-T82 2M Photoelectric Sensors
Datasheet
BrandOmron
ProductPhotoelectric Sensors
Model NumberE3Z-T82 2M

Omron E3Z-T82 2M Photoelectric Sensor – Technical Specifications

SpecificationValue
Sensing MethodThrough-beam
Sensing Distance30 m
Emitter NumberE3Z-T82-L 2M
Receiver NumberE3Z-T82-D 2M
Standard Sensing ObjectOpaque: 12-mm dia. min.
Light SourceInfrared LED (870 nm)
Power Supply Voltage12 to 24 VDC
Output ConfigurationPNP
Connection MethodPre-wired 2 M cable
Current Consumption35 mA max. (Emitter: 15 mA max., Receiver: 20 mA max.)
Control OutputLoad power supply voltage: 26.4 VDC max., Load current: 100 mA max. Residual voltage: Load current of less than 10 mA: 1 V max. Load current of 10 to 100 mA: 2 V max.
Operation ModeLight-ON/Dark-ON selectable
Response TimeOperate or reset: 2 ms max.
Sensitivity AdjustmentOne-turn adjuster
IndicatorsOperation indicator (orange), Stability indicator (green), Through-beam Emitter has power indicator (orange) only.
Ambient IlluminationIncandescent lamp: 3,000 lx max. Sunlight: 10,000 lx max.
Ambient Temperature RangeOperating: −25 to 55°C, Some connector models: −40°C to 55°C, Storage: −40 to 70°C (with no icing or condensation)
Ambient Humidity RangeOperating: 35% to 85%, Storage: 35% to 95% (with no condensation)
Insulation Resistance20 MΩ min. at 500 VDC
Dielectric Strength1,000 VAC, 50/60 Hz for 1 min
Vibration ResistanceDestruction: 10 to 55 Hz, 1.5 mm double amplitude for 2 hours each in X, Y, and Z directions
Shock ResistanceDestruction: 500 m/s2 3 times each in X, Y, and Z directions
Protection CircuitsReversed power supply polarity protection, Output short-circuit protection, and Reversed output polarity protection
Degree Of ProtectionIEC, IP67
MaterialPBT (polybutylene terephthalate), Modified polyarylate
WeightApprox. 30 g
