Omron E3T-FD14 2M Ultracompact Photoelectric Sensor
Omron E3T-FD14 2M is an ultrathin diffuse-reflective photoelectric sensor designed for object sensing across a short 5 to 30 mm range. Its red LED sends light toward the target, while the built-in amplifier processes the returned optical signal. A PNP output provides the switching state to compatible industrial control circuitry, and Dark-ON operation defines the specified logic. The sensor operates from 12 to 24 VDC, consumes up to 20 mA, and responds within 1 ms max. A 2 m pre-wired cable supports direct electrical connection, while the rectangular format suits compact mounting positions. Within the E3T Series, the E3T-FD14 2M provides the Dark-ON PNP configuration. Related Dark-ON diffuse sensors can be compared across Omron Automation Sensors.
| Brand | Omron |
| Product | Photoelectric Sensors |
| Model Number | E3T-FD14 2M |
Omron E3T-FD14 2M Photoelectric Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensing Method | Diffuse-reflective |
| Shape | Rectangular type |
| Sensing Distance | 5 to 30 mm |
| Power Supply Voltage | 12 to 24 VDC |
| Output Configuration | PNP |
| Connection Method | Pre-wired cable length 2m |
| Current Consumption | 20 mA max. |
| Light Source (Wavelength) | Red LED |
| Operation Mode | Dark-ON |
| Response Time | 1 ms max. |
| Degree Of Protection | IP67 |
| Material | Polybutylene terephthalate |
| Material Lens | Denatured Polyarylate |
| Weight | 20g |
The Omron E3T-FD14 2M Photoelectric Sensor uses diffuse-reflective sensing across a 5 to 30 mm range in an ultrathin rectangular body. A red LED sends light toward the target, and the built-in amplifier processes the returned optical signal to establish the switching state. Its PNP output transfers the result to compatible PLC inputs and machine-control circuits, while Dark-ON operation defines the specified logic. The sensor operates from a 12 to 24 VDC supply and consumes up to 20 mA. Operate or reset time is specified at 1 ms max. A 2 m pre-wired cable provides direct electrical connection. The compact format supports short-distance sensing where mounting depth and available installation area are limited.
For an Omron PNP Dark ON photoelectric sensor requiring a 5 to 30 mm sensing range, the relevant model is the E3T-FD14. Polybutylene terephthalate is listed for the housing and denatured polyarylate for the optical section. IP67 protection is specified, while approximate sensor weight is 20 g. Its configuration also suits searches for an Omron short range PNP sensor and Omron ultrathin diffuse sensor. The 1 ms response supports quick switching for component presence, small-part positioning, and edge confirmation in compact automated equipment. For the related PNP model using Light-ON operation with the same sensing range and 2 m cable format, see E3T-FD13 2M.
