Omron E32-C91N 2M Fiber Optic Sensor
Omron E32-C91N 2M is an M6 diffuse-reflective fiber optic sensor designed for object detection at sensing distances up to 1170 mm. Its threaded sensing head combines a right-angle optical surface with a 90° cable exit and hexagonal back, providing a defined arrangement for mounting and cable routing. A small-spot lens concentrates the sensing area for target detection, while flexible fiber construction supports installation through compact spaces. The 2 m fiber uses a plastic core with a polyethylene sheath and has an R4 bending radius. IP67 protection supports industrial sensing environments. The E32-C91N 2M belongs to the E32 Series within the diffuse fiber optic sensor range from Omron sensing products, combining M6 mounting with small-spot object detection.

| Brand | Omron |
| Product | Fiber Optic Sensor |
| Model Number | E32-C91N 2M |
Omron E32-C91N 2M Fiber Optic Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Shape | Threaded |
| Sensing Distance | 1170 mm |
| Connection Method | Cable |
| Size | M6 |
| Cable Length | 2 m |
| Sensing Method | Diffuse reflective |
| Application | Object detection |
| Features | 90° cable exit, Flexible fiber, Hexagonal back, Small spot with lens |
| Sensing Surface Orientation | Right-angle |
| Tightening Torque | 0.98N · m |
| Temperature Range | 40-70 °C |
| Bending Radius | R4 |
| Material Core | Plastic |
| Material Sheath | Polyethylene |
| Degree Of Protection Ip | IP67 |
The Omron E32-C91N 2M Fiber Optic Sensor uses diffuse-reflective sensing for object detection at distances up to 1170 mm. Its threaded M6 sensing head provides a defined mounting interface, while the right-angle optical surface changes the sensing direction relative to the cable path. A 90° cable exit and hexagonal back further define the installation geometry. The small-spot lens concentrates the sensing area, making spot size an important characteristic where a focused optical detection point is required. Flexible fiber construction supports routing between the sensing location and compatible fiber amplifier. The 2 m fiber uses a plastic core with a polyethylene sheath and has an R4 bending radius. IP67 protection defines the supplied enclosure rating. Important characteristics include M6 threaded mounting, diffuse-reflective sensing, small-spot detection, right-angle orientation, flexible fiber and 1170 mm sensing distance. Within the E32 Series, head size, lens configuration, optical direction and fiber construction help distinguish related diffuse sensing heads. The E32-C91N therefore combines focused object detection with flexible right-angle installation. For another supplied M6 diffuse-reflective E32 model with a small-spot lens, right-angle sensing surface and the same 1170 mm sensing distance, the E32-C11N 2M provides the closest related comparison.
