Omron E2NC-EV05 Proximity Sensor
Omron E2NC-EV05 is a smart flat, shielded proximity sensor with a 5 mm sensing distance and connector connection. Ferrous metal is the specified detectable object, using a 15 × 15 mm standard sensing object. The model is rated for operation from -10 to 60°C and storage from -20 to 70°C without icing or condensation, with 35% to 85% humidity for both conditions. Zinc, heat-resistant ABS, nickel-plated brass, zinc-plated iron, and PES are listed among the construction materials. IP67 protection is specified for the sensor. Its flat sensing form uses a standard connector rather than a pre-wired cable. The E2NC-EV05 is listed under smart proximity sensors from Omron industrial sensing.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2NC-EV05 |
Omron E2NC-EV05 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Flat |
| Sensing Distance | 5 mm |
| Connection | Connector |
| Cable Specifications | Standard |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | 15 × 15 mm |
| Ambient Temperature Range | Operating:-10°C to 60°C (with no icing or condensation) Storage:-20°C to 70°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 85% (with no condensation) |
| Material | Zinc, Heat-resistant ABS, Nickel-plated brass, Zinc-plated iron, PES |
| Degree Of Protection | IP67 |
| Weight | Approx. 120 g |
The Omron E2NC-EV05 Proximity Sensor uses a smart flat, shielded sensing structure with a 5 mm sensing distance and standard connector connection. Ferrous metal is the specified detectable object, with a 15 × 15 mm standard sensing object. The flat sensing form is paired with connector wiring rather than a pre-wired cable. Operating temperature is -10 to 60°C, while storage temperature is -20 to 70°C without icing or condensation. Operating and storage humidity is 35% to 85%. Zinc, heat-resistant ABS, nickel-plated brass, zinc-plated iron, and PES are listed among the construction materials. The sensor is specified with IP67 protection for the stated operating environment.
Environmental specifications for the E2NC-EV05 retain the same 35% to 85% humidity range during operation and storage, with the temperature limits separated between active use and storage conditions. The 5 mm shielded sensing distance is combined with a flat body and standard connector interface. Heat-resistant ABS and the listed metal components form the construction materials, while IP67 defines the protection level. For another shielded E2NC sensor using connector connection but a screw-type body and a shorter 2 mm sensing distance, see E2NC-EM02. That model uses a 10 × 10 mm specified standard sensing object instead.
