Omron E2E-X3D1-M1TGJ-U 0.3M Proximity Sensor
Omron E2E-X3D1-M1TGJ-U 0.3M uses a cylindrical M12 shielded body with 3 mm sensing and DC 2-wire normally open operation. An M12 pre-wired Smartclick connector with a 0.3 m PUR cable provides connection, while the setting range extends from 0 to 2.4 mm. Operating voltage is 12 to 24 VDC with a 1 kHz response frequency. The E2E-X3D1-M1TGJ-U 0.3M belongs to the E2E Series, while similar connection options appear in the wider M12 Smartclick proximity sensor range available from Omron Sensors.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X3D1-M1TGJ-U 0.3M |
Omron E2E-X3D1-M1TGJ-U 0.3M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M12 |
| Mounting type | Shielded |
| Sensing Distance | 3 mm |
| Setting Distance | 0 to 2.4 mm |
| Output configuration | DC 2-Wire |
| Operation Mode | NO |
| Connection Method | M12 Pre-wired Smartclick Connector 0.3 M Cable |
| Cable specifications | PUR |
| Wire color / pin arrangement | 1: +V, 4: 0 V |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 12 × 12 × 1 mm |
| Response Frequency | 1 kHz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient Temperature Range | Operating: −25 to 70°C, Storage: −40 to 85°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67 |
| Control Output | 4 to 100 mA, Diagnostic output: 50 mA |
| Indicators | Operation indicator (red) and setting indicator (green) |
| Materials | Stainless steel (SUS303), PBT, Nickel-plated brass, Zinc-plated iron. |
| Weight | Approx. 40 g |
The Omron E2E-X3D1-M1TGJ-U 0.3M Proximity Sensor uses a cylindrical M12 shielded body with a 3 mm sensing distance and a setting range from 0 to 2.4 mm. DC 2-wire normally open operation is provided through an M12 pre-wired Smartclick connector with a 0.3 m PUR cable. The sensor operates from 12 to 24 VDC with a 1 kHz response frequency, while ferrous metal is specified using an iron 12 × 12 × 1 mm standard object. Load current ranges from 4 to 100 mA with a 50 mA diagnostic output. Surge suppression and load short-circuit protection are included. The shielded M12 construction supports compact threaded mounting, while the short PUR lead provides a connector-based wiring format without using a long fixed cable.
For an Omron M12 proximity sensor requiring shielded 3 mm sensing, DC 2-wire NO operation, and Smartclick connection, the applicable model is the E2E-X3D1-M1TGJ-U. Operating temperature covers -25 to 70°C and storage extends from -40 to 85°C, with IEC 60529 IP67 specified. Its electrical format also suits Omron 2-wire proximity sensor, Omron 3 mm proximity sensor, Omron shielded proximity sensor, and Omron Smartclick proximity sensor requirements. The 1 kHz response frequency provides a useful switching rate for short-range sensing specifications. For a related M12 shielded 3 mm two-wire NO version using a standard connector, see E2E-X3D1S-M1.
