Omron E2E-X2C18 2M Proximity Sensor
Omron E2E-X2C18 2M is a compact M8 shielded inductive proximity sensor with a 2 mm sensing distance, 0 to 1.6 mm setting distance, and short-body construction. It provides a DC 3-wire NPN output with NO operation through a pre-wired 2 m cable and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, with an iron 8 × 8 × 1 mm standard sensing object. Response frequency is 1,500 Hz, while the listed 1-output rating is 200 mA max. Standard I/O and IO-Link indication are also specified. The E2E-X2C18 2M is listed among M8 NPN proximity sensors from Omron industrial automation sensors.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X2C18 2M |
Omron E2E-X2C18 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M8 |
| Mounting type | Shielded |
| Sensing Distance | 2 mm |
| Setting Distance | 0 to 1.6 mm |
| Output configuration | DC 3-Wire NPN |
| Operation Mode | NO |
| Body Length | Short Body |
| Connection Method | Pre-wired 2 M Cable |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 8 × 8 × 1 mm |
| Response Frequency | 1,500 Hz |
| Power Supply Voltage | 10 to 30 VDC |
| Protection Circuit | Power supply reverse polarity protection, Surge suppressor, Output short-circuit protection, Output reverse polarity protection |
| Ambient Temperature Range | Operating/Storage: 35% to 95% |
| Degree of Protection | IEC 60529:IP67, ISO 20653 |
| Control Output | 1-output models: 10 to 30 VDC, Class 2, 200 mA max. 2-output models: 10 to 30 VDC, Class 2, 50 mA max. |
| Indicators | In the Standard I/O mode (SIO mode): Operation indicator (orange, lit) and communication indicator (green, not lit) In the IO-Link communication mode (COM mode): Operation indicator (orange, lit) and communication indicator (green, blinking at 1 s intervals) |
| Materials | Stainless (SUS303), Polybutylene terephthalat (PBT), Nickel-plated brass, Zinc-plated iron, Vinyl chloride (PVC). |
| Weight | Approx. 85 g |
The Omron E2E-X2C18 2M Proximity Sensor uses an M8 shielded inductive sensing body with a 2 mm sensing distance, a 0 to 1.6 mm setting distance, and short-body construction. It provides a DC 3-wire NPN output with NO operation through a pre-wired 2 m cable and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, with an iron 8 × 8 × 1 mm standard sensing object. Response frequency is 1,500 Hz. The supplied data lists 200 mA max. for 1-output models and 50 mA max. for 2-output models. Power-supply reverse-polarity, surge, output short-circuit, and output reverse-polarity protection are specified.
The supplied environmental data for the E2E-X2C18 lists 35% to 95%, while IEC 60529 IP67 and ISO 20653 are provided as protection specifications. SUS303 stainless steel, PBT, nickel-plated brass, zinc-plated iron, and PVC are listed among the construction materials. The compact shielded M8 body combines a 2 mm sensing range with NPN NO switching and direct 2 m cable wiring. Its 1,500 Hz response supports rapid target detection within the specified range. Standard I/O mode provides orange operation indication, while IO-Link communication mode also uses a green communication indicator. This model is intended for ferrous-metal detection in compact machine sensing positions.
