E2E-C06S02-WC-C1 2M: NPN NO Inductive Proximity Sensor in Chennai
The technical specifications for Omron E2E-C06S02-WC-C1 2M NPN NO Inductive Proximity Sensor are:
- Sensor Head (Dia): 6.5 dia.
- Installation: Flush | Shielded
- Sensing Distance: 2 mm
- Connection Method: Pre-wired Models
- Cable Specifications: PVC (oil-resistant)
- Switching: NO
- Output: NPN
- Response frequency: 3 kHz
- Power supply voltage: 10 to 30 VDC
Omron E2E-C06S02-WC-C1 2M NPN NO Inductive Proximity Sensor Technical Specification:
| Sensor Head (Dia) | 6.5 dia. |
| Installation | Flush | Shielded |
| Sensing Distance | 2 mm |
| Connection Method | Pre-wired Models (2 m) |
| Cable Specifications | PVC (oil-resistant) |
| Switching | NO |
| Output | NPN |
| Differential travel | 15% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard sensing object | Iron, 6.5 × 6.5× 1 mm |
| Response frequency | 3 kHz |
| Power supply voltage | 10 to 30 VDC (including 10% ripple (p-p)) |
| Current consumption | 10 mA max. |
| Indicator | Operation indicator: Yellow (complies with European standard EN60947-5-2) Lights during output |
| Protection circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, and Load short-circuit protection. |
| Ambient air temperature | Operation and storage: −25 to 70°C (with no icing or condensation) |
| Ambient humidity | Operation and storage: 35% to 95% (with no condensation) |
| Temperature influence | ±15% max. of sensing distance at 23°C within a temperature range of −25 to 70°C |
| Voltage influence | ±2.5% max. of sensing distance at a rated voltage in the rated voltage ±15% range |
| Degree of protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Material Sensing Surface | Heat-resistant ABS |
Looking for Omron E2E-C06S02-WC-C1 2M in Chennai ? You’ve found the right spot. This sensor has a 6.5mm diameter, flush/shielded installation, 2 mm sensing, pre-wired connection, oil-resistant PVC cable, NPN NO Inductive Proximity Sensor, 3 kHz response, and 10-30 VDC power. It best detects ferrous metals. Get the best prices for these sensors at IndMALL Automation.
