Omron E2E-C06N04-MC-B1 Small-diameter Proximity Sensor
Omron E2E-C06N04-MC-B1 is a small-diameter 6.5 mm unshielded inductive proximity sensor with a 4 mm sensing distance and 0 to 2.8 mm setting distance. It provides a DC 3-wire PNP output with NO operation through a 3-pin M8 connector and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, with an iron 12 × 12 × 1 mm standard sensing object. Response frequency is 3 kHz, while control output is rated 200 mA max., reduced to 100 mA from 60 to 70°C. The E2E-C06N04-MC-B1 is part of small-diameter proximity sensors from Omron industrial sensors for compact automation systems.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-C06N04-MC-B1 |
Omron E2E-C06N04-MC-B1 Small-diameter Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | 6.5 dia. |
| Mounting type | Unshielded |
| Sensing Distance | 4 mm |
| Setting Distance | 0 to 2.8 mm |
| Output configuration | DC 3-wire PNP |
| Operation Mode | NO |
| Connection Method | M8 Connector, 3-pin |
| Wire color / pin arrangement | 1: +V, 3: 0 V, 4: Control output |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 12 × 12 × 1 mm |
| Response Frequency | 3 kHz |
| Power Supply Voltage | 10 to 30 VDC |
| Protection Circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operation and storage: −25 to 70°C |
| Degree of Protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Control Output | 200 mA max. (60 to 70°C: 100 mA), 2 V max. |
| Indicators | Operation indicator: Yellow (complies with European standard EN60947-5-2) Lights during output. |
| Materials | Nickelplated brass, Heat-resistant ABS, No, No, Polyvinyl chloride (PVC) |
| Weight | Approx. 15 g |
The Omron E2E-C06N04-MC-B1 Small-diameter Proximity Sensor uses a 6.5 mm cylindrical unshielded inductive sensing body with a 4 mm sensing distance and 0 to 2.8 mm setting distance. It provides a DC 3-wire PNP output with NO operation through a 3-pin M8 connector and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, with an iron 12 × 12 × 1 mm standard sensing object. Response frequency is 3 kHz. Control output is rated 200 mA max., reducing to 100 mA from 60 to 70°C, with a 2 V max. voltage drop. Output reverse-polarity, power-source reverse-polarity, surge, and load short-circuit protection are specified.
Operating and storage conditions for the E2E-C06N04-MC-B1 cover -25 to 70°C. IEC 60529 IP67 and an in-house oil-resistant rating are listed for environmental protection. The small 6.5 mm body is suited to restricted mounting spaces, while the unshielded sensing face provides the stated 4 mm detection range. A yellow indicator lights during output, and the M8 connector permits detachable field wiring during replacement or maintenance. Nickel-plated brass, heat-resistant ABS, and PVC are listed among the construction materials. For another small-diameter E2E model in the supplied product set, see E2E-C03SR8-WC-B1 5M.
