Omron E2B-M12LN05-M1-B1 Proximity Sensor
Omron E2B-M12LN05-M1-B1 combines an M12 unshielded inductive sensing structure with a 5 mm sensing distance and long-body construction. It uses a DC 3-wire PNP output with NO operation through an M12 connector and operates from 10 to 30 VDC. Ferrous metal is specified as the detectable object, with a 15 × 15 × 1 mm standard sensing object. Response frequency is 800 Hz, current consumption is 10 mA max., and differential travel is 10% max. of sensing distance. A yellow operation indicator and reverse-polarity, surge, short-circuit, and IP67 protection are listed. The E2B-M12LN05-M1-B1 is listed among M12 inductive sensors from Omron automation products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2B-M12LN05-M1-B1 |
Omron E2B-M12LN05-M1-B1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M12 |
| Mounting | Unshielded |
| Sensing Distance | 5 mm |
| Body Length | Long Body |
| Output | DC 3-wire |
| Output Configuration | PNP |
| Operation Mode | NO |
| Connection | M12 Connector |
| Power Supply Voltage | 10 to 30 VDC |
| Differential Travel | 10% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard Sensing Object | 15 × 15 × 1 mm |
| Response Frequency | 800HZ |
| Current Consumption | 10 mA max |
| Indicator | Operation indicator (Yellow LED) |
| Protection Circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient Temperature Range | Operation and storage : -25 to 70ºC (with no icing or condensation) |
| Ambient Humidity Range | Operation and Storage: 35 to 95% |
| Voltage Influence | ±1% max. of sensing distance in 24 VDC ±15% |
| Standard And Listings | (1) IP67 (IEC60529) (2) EMC (EN60947-5-2) |
| Material Case | Stainless steel (1.4305 (W.-No.), SUS 303 (AISI), 2346 (SS).) |
| Material Sensing Surface | PBT |
| Material Cable | Standard cable is 4 mm dia. PVC. |
| Material Clamping Nut | Brass-nickel plated |
The Omron E2B-M12LN05-M1-B1 Proximity Sensor combines an M12 unshielded inductive sensing structure with a 5 mm sensing distance and long-body construction. It uses a DC 3-wire PNP output with NO operation through an M12 connector and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, with a 15 × 15 × 1 mm standard sensing object. Response frequency is 800 Hz, current consumption is 10 mA max., and differential travel is 10% max. of sensing distance. A yellow operation indicator is provided. Output reverse-polarity protection, power-source reverse-polarity protection, surge suppression, and short-circuit protection are included in the specified electrical protection.
For the E2B-M12LN05-M1-B1, operation and storage are rated from -25 to 70°C without icing or condensation, with humidity from 35% to 95%. Voltage influence is ±1% max. of sensing distance at 24 VDC ±15%. IP67 according to IEC 60529 and EMC according to EN60947-5-2 are listed. Stainless steel is specified for the case, PBT for the sensing surface, and brass with nickel plating for the clamping nut. The M12 connector provides the specified electrical connection interface. For another M12 PNP NO E2B model using a long body and M12 connector but a shielded 2 mm sensing configuration, see E2B-M12LS02-M1-B1.
