Omron E2A-S08KS02-M3-B1 Proximity Sensor
Omron E2A-S08KS02-M3-B1 is an M8 shielded inductive proximity sensor with a 2 mm sensing distance, 0 to 1.6 mm setting distance, and short-body design. It provides a DC 3-wire PNP output with NO operation through a 4-pin M8 connector and operates from 12 to 24 VDC. Response frequency is 1,500 Hz, while control output is rated 200 mA max. at 32 VDC max. with a 2 V max. voltage drop. A yellow LED shows operation, while power-source reverse-polarity protection, surge suppression, and short-circuit protection are specified. The E2A-S08KS02-M3-B1 is part of M8 PNP proximity sensors from Omron industrial automation products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2A-S08KS02-M3-B1 |
Omron E2A-S08KS02-M3-B1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M8 |
| Mounting type | Shielded |
| Sensing Distance | 2 mm |
| Setting Distance | 0 to 1.6 mm |
| Output configuration | DC, 3-wire, PNP |
| Operation Mode | NO |
| Body Length | Short body |
| Connection Method | M8 Connector (4-pin) |
| Response Frequency | 1,500 Hz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient Temperature Range | Operating: −40°C to 70°C, Storage: −40°C to 85°C |
| Degree of Protection | IP67 after IEC 60529, IP69k after DIN 40050, EMC after EN60947-5-2 |
| Control Output | 200 mA max. (32 VDC max.), 2 V max. |
| Indicators | Operation indicator (Yellow LED) |
| Materials | Stainless steel or brass-nickel plated, PBT, PVC, Brass-nickel plated |
| Weight | Approx. 15 g |
The Omron E2A-S08KS02-M3-B1 Proximity Sensor uses a cylindrical M8 shielded inductive sensing body with a 2 mm sensing distance, a 0 to 1.6 mm setting distance, and short-body construction. It provides a DC 3-wire PNP output with NO operation through a 4-pin M8 connector and operates from 12 to 24 VDC. Response frequency is 1,500 Hz, while control output is rated 200 mA max. at 32 VDC max. with a 2 V max. voltage drop. A yellow LED indicates operation, while power-source reverse-polarity protection, surge suppression, and short-circuit protection are specified. Stainless steel or brass-nickel-plated material and PBT are listed for the sensor construction.
Operating conditions for the E2A-S08KS02-M3-B1 cover -40 to 70°C, with storage from -40 to 85°C. IP67 according to IEC 60529, IP69K according to DIN 40050, and EMC according to EN60947-5-2 are specified. The shielded M8 format supports close metal mounting, and its compact short body reduces required rear space. PNP NO switching works through a detachable M8 connector, while the 1,500 Hz response frequency supports rapid sensing within the stated 2 mm range. For another E2A M8 model with a longer 4 mm sensing distance and a 3-pin M8 connector, see E2A-S08LN04-M5-B1.
