The Omron CS1D-PD024 PLC Power Supply Unit supports duplex Programmable Logic Controller architectures with 5 VDC at 5 A and 24 VDC at 0.4 A output capacity. The unit supports redundant power operation for CS1D duplex CPU systems, allowing the power architecture to be configured for applications where continued controller operation is required. Its dual-output configuration supplies compatible components within the CS1D system while supporting the redundancy structure of the controller platform. This makes the unit part of the power infrastructure for duplex industrial control architectures. The CS1D-PD024 supports CS1D duplex systems and forms part of the redundant PLC power supply range associated with Omron industrial control systems.
5 V DC, 4.3 A (including the CPU Unit power supply)
26 V DC, 0.56 A
Total: 28 W max.
Insulation Resistance
20 MΩ min. (at 500 V DC)
between DC external and
GR terminals
Dielectric Strength
1,000 V AC 50/60 Hz for 1
min between DC external
and GR terminals
Leakage current: 10 mA
max.
Grounding
Less than 100 Ω
Ambient operating temperature
0 to 55°C
Ambient storage temperature
−20 to 75°C (excluding battery)
Ambient operating humidity
10% to 90% (with no condensation)
Atmosphere
Must be free from corrosive gases
Enclosure
Mounted in a panel.
Power Supply Voltage
24 V DC
Power Consumption
40 W max.
Noise immunity
2 kV on power supply line
Vibration resistance
10 to 57 Hz, 0.075-mm amplitude, 57 to 150 Hz, acceleration: 9.8 m/s2 in X, Y, and Z
directions for 80 minutes
(Time coefficient: 8 minutes × coefficient factor 10 = total time 80 min.)
