Omron CP2E-S30DR-A Programmable Logic Controller
The Omron CP2E-S30DR-A PLC CPU Unit combines 18 inputs and 12 relay outputs within a compact configuration for machine-control applications. This Programmable Logic Controller provides a program capacity of 8K steps and 8K words of data memory for executing control logic and storing operating information. It operates from a 100 to 240 VAC, 50/60 Hz supply with an operating voltage range of 85 to 264 VAC. Current consumption is 0.12 A at 5 V and 0.07 A at 24 V. The CP2E-S30DR-A integrates CPU processing with relay output control and belongs to the compact relay PLC range supporting Omron machine automation.
| Brand | Omron |
| Product Type | Programmable Logic Controller |
| Model Number | CP2E-S30DR-A |
Omron CP2E-S30DR-A Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Number of points | CPU Units with 30 points |
| Inputs | 18 points |
| Outputs | 12 points |
| Output type | Relay |
| Program capacity | 8K steps (FB capacity: 8K steps) |
| Data memory capacity | 8K words |
| Current consumption 5 VDC | 0.12 A |
| Current consumption 24 VDC | 0.07 A |
| Dimensions (H × D × W) | 90mm *1 × 80mm *2 × 130mm |
| Supply voltage | 100 to 240 VAC 50/60 Hz |
| Operating voltage range | 85 to 264 VAC |
| Power consumption | 50 VA/100 VAC max., 70 VA/240 VAC max. |
| Inrush current | 120 VAC, 20 A for 8 ms max. for cold start at room temperature, 240 VAC, 40 A for 8 ms max. for cold start at room temperature |
| Insulation resistance | 20 MΩ min. (at 500 VDC) between the external AC, terminals and GR terminals |
| Power interrupt time | 10 ms min. |
| Altitude | 2,000 m max |
| Atmosphere | No corrosive gas |
| Ambient humidity | 10% to 90% |
| "Ambient operating temperature" | 20 to 60°C |
| Ambient storage temperature | -20 to 75°C (excluding battery) |
| Weight | 580g max |
The Omron CP2E-S30DR-A PLC delivers dependable control with 30 I/O points, including 18 inputs and 12 relay outputs. It supports 8K steps of programming capacity and 8K words of data memory, making it ideal for straightforward automation tasks where precision and durability matter. Its relay-type output ensures compatibility with a wide range of industrial devices, offering flexible deployment across systems.
Built to operate on a standard 100 to 240 VAC supply, this PLC functions within an 85 to 264 VAC voltage range and consumes up to 70 VA at peak load. It features compact dimensions of 90mm × 80mm × 130mm, allowing easy integration into control cabinets. With a current draw of just 0.12 A at 5 VDC and 0.07 A at 24 VDC, the CP2E-S30DR-A ensures energy efficiency without compromising performance.
Engineered for industrial reliability, this Omron PLC withstands ambient temperatures from -20°C to 60°C, offers 20 MΩ insulation resistance, and tolerates power interruptions of up to 10 ms. It is suitable for installations up to 2,000 meters in altitude and environments free from corrosive gases. Trusted by system integrators and manufacturers alike, the CP2E-S30DR-A combines affordability with Omron’s renowned quality.
