The Omron CJ1W-SPU01-V2 PLC High-speed Data Storage Unit collects process, operation, and inspection information from CJ-series Programmable Logic Controller systems for external data storage. In Data Storage Mode, it supports up to 7,776 words and 65 collection patterns, with collected information stored as CSV files on external CompactFlash media. The unit also provides 10/100Base-TX Ethernet communication, recipe management, and FTP client functions for handling automation data. Current consumption is 560 mA at 5 VDC, and its dimensions are 51 × 90 × 65 mm. The CJ1W-SPU01-V2 extends CJ1W data handling and belongs to the PLC data storage range within Omron industrial automation.
Displays error information and operating status of the SPU Unit.
Displays the command number set on the select switch.
Displays the IP address.
Display other information.
Current consumption
5 VDC, 560 mA max. (SPU Unit only)
Other: Memory Card (HMCEF[][][]): 120 mA max.
(Supplied from Power Supply Unit.)
