Mitsubishi R60DA16-G - PLC Analog Output Module
The Mitsubishi R60DA16-G Programmable Logic Controller provides 16 channel-isolated analog outputs with voltage and current ranges suitable for precise process control. Manufactured by Mitsubishi, it is part of the Mitsubishi Programmable Logic Controller family under the MELSEC IQ-R Series. Operating on a 24V DC power supply with 0.25A current consumption, it delivers reliable analog output performance in industrial automation setups, measuring 98 mm height and weighing 0.32 kg.
| Brand | Mitsubishi |
| Product Type | PLC Analog Output Module |
| Product | R60DA16-G |
Mitsubishi PLC Analog Output Module R60DA16-G Technical Specifications
| Specification | Value |
|---|---|
| Series | MELSEC IQ-R SERIES |
| Type | CHANNEL ISOLATED ANALOG OUTPUT |
| Occupied I/O Points on PLC | 48 |
| Wiring | SCREW |
| Int. Current Consumption (A) | 0,25 |
| Depth (mm) | 110 |
| Weight (kg) | 0,32 |
| Width (mm) | 56 |
| Height (mm) | 98 (106) |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Analogue Outputs | 16 |
| Output Voltage Range (V) | -12-12; -10-10; 0-5; 1-5 |
| Output Current Range (mA) | 0-20; 4-20 |
The Mitsubishi R60DA16-G Programmable Logic Controller is a channel-isolated analog output module from the MELSEC IQ-R Series. It supports 16 output channels with configurable voltage and current ranges including 0–20mA, 4–20mA, and -10–10V. With 24V DC power input and 0.25A current consumption, this module ensures high accuracy and dependable analog signal generation for automation systems.
The Mitsubishi R60DA16-G PLC module is ideal for use in process control, packaging, and machine automation applications where precision analog output is required. Its screw wiring and compact dimensions allow easy installation and integration with other IQ-R Series components. The module delivers stable performance in industrial environments requiring signal consistency for controllers, drives, and monitoring systems.
The Mitsubishi R60DA16-G Programmable Logic Controller combines Mitsubishi’s trusted design with proven reliability for industrial automation. As part of the MELSEC IQ-R Series, it ensures precise output control and seamless communication within automation networks. With 16 analog outputs and robust electrical design, the R60DA16-G module offers consistent, efficient, and dependable performance for demanding industrial processes.
