Mitsubishi R60ADI8-HA - PLC Analog Output Module
The Mitsubishi R60ADI8-HA Programmable Logic Controller offers 8 analog input channels with HART communication support for precise signal monitoring in automation systems. Designed by Mitsubishi, it is part of the Mitsubishi Programmable Logic Controller family under the MELSEC IQ-R Series. Operating on a 24V DC power supply with 0.17A current consumption, it features spring clamp wiring and compact dimensions of 98 mm height, 27.8 mm width, and 125 mm depth.
| Brand | Mitsubishi |
| Product Type | PLC Analog Output Module |
| Product | R60ADI8-HA |
Mitsubishi PLC Analog Output Module R60ADI8-HA Technical Specifications
| Specification | Value |
|---|---|
| Series | MELSEC IQ-R SERIES |
| Type | ANALOG INPUT (HART) |
| Occupied I/O Points on PLC | 16 |
| Integrated Analogue Inputs | 8 |
| Input Current Range (mA) | 0-20; 4-20 |
| Wiring | SPRING CLAMP |
| Int. Current Consumption (A) | 0,17 |
| Depth (mm) | 125 |
| Weight (kg) | 0,21 |
| Width (mm) | 27,8 |
| Height (mm) | 98(106) |
| Power Supply (V) | 24 |
| Current Type | DC |
The Mitsubishi R60ADI8-HA Programmable Logic Controller is a specialized analog input module from the MELSEC IQ-R Series. It features 8 analog inputs with HART protocol compatibility, enabling both current and digital signal acquisition. Operating on a 24V DC supply with 0.17A current draw, this module provides efficient, stable, and accurate input measurement for industrial automation control systems.
The Mitsubishi R60ADI8-HA PLC is ideal for process industries, manufacturing, and automation systems that require precise data acquisition and communication. Its HART compatibility allows simultaneous analog and digital signal transmission, improving diagnostic accuracy. Compact design and spring clamp wiring simplify installation while ensuring strong, reliable connectivity in high-performance control environments.
The Mitsubishi R60ADI8-HA Programmable Logic Controller combines dependable analog input performance with HART integration, making it a trusted choice for modern industrial setups. Belonging to the MELSEC IQ-R Series, it reflects Mitsubishiβs reputation for reliable automation hardware engineered for consistency, accuracy, and long-term operational stability across diverse industrial applications.
