Mitsubishi LM-H3P7C-72P-ASS0 - Linear Servo Motors
Mitsubishi LM-H3P7C-72P-ASS0 Servo Motor delivers 720N rated thrust, 1800N maximum thrust, and 3m/s maximum speed for linear motion systems. The LM-H3P7C-72P-ASS0 Mitsubishi Linear Servo Motors unit operates with 10.2A rated current, 28.6A maximum current, IP00 protection, 3.8kVA power capacity, 6600N magnetic attraction force, natural cooling, and primary-side LM-H3 construction. This model belongs to the MELSERVO-JET, MELSERVO-J5, MELSERVO-J4 series used in industrial automation.
| Brand | Mitsubishi |
| Product Type | Linear Servo Motors |
| Product | LM-H3P7C-72P-ASS0 |
Mitsubishi Linear Servo Motors LM-H3P7C-72P-ASS0 Technical Specifications:
| Specification | Value |
|---|---|
| Rated Current (A) (fa_ger_79) | 10,2 |
| Maximum current (A) | 28,6 |
| Protection Class | IP00 |
| Series | MELSERVO-JET, MELSERVO-J5, MELSERVO-J4 |
| Type | LM-H3 |
| Cooling method | NATURAL |
| Side | PRIMARY |
| Power supply capacity (kVA) | 3,8 |
| Magnetic attraction force (N) | 6600 |
| Rated thrust (N) | 720 |
| Maximum thrust (N) | 1800 |
| Maximum Speed (m/s) | 3 |
| Lenght (mm) | 320 |
| Depth (mm) | 320 |
| Weight (kg) | 5,6 |
| Width (mm) | 100 |
| Height (mm) | 32 |
LM-H3P7C-72P-ASS0 Mitsubishi Linear Servo Motors is a primary-side LM-H3 motor engineered for controlled linear motion in industrial automation systems. It provides 720N rated thrust, 1800N maximum thrust, and 3m/s maximum speed with a 10.2A rated current. This Mitsubishi servo motor operates with IP00 protection, natural cooling, and 3.8kVA power supply capacity within the MELSERVO-JET, MELSERVO-J5, and MELSERVO-J4 series platform.
In conveyor positioning, packaging lines, assembly automation, and transfer mechanisms, LM-H3P7C-72P-ASS0 ensures stable thrust output and consistent motion speed. The 6600N magnetic attraction force supports controlled primary-side operation under defined load conditions. Mitsubishi Linear Servo Motors are selected where repeatable linear travel and predictable electrical performance are required.
LM-H3P7C-72P-ASS0 Mitsubishi Linear Servo Motors integrates 320mm mechanical dimensions and 5.6kg weight for structured machine layouts. As part of the Mitsubishi MELSERVO architecture, this servo motor supports reliable thrust generation and stable speed control for industrial automation applications.
