Mitsubishi HG-SN202JK - Servo Motors
The Mitsubishi HG-SN202JK Servo Motor delivers 2 kW capacity, 9.55 Nm torque, and 2000 rpm speed for stable industrial motion control applications. This motor belongs to the Mitsubishi servo family, accessible at mitsubishi electric, and features medium inertia, AC operation, 17-bit encoder, 131072 p/rev resolution, IP67 protection, and a keyway shaft. More Mitsubishi servo motor options can be viewed at mitsubishi electric within the MELSERVO-JE series category.
| Brand | Mitsubishi |
| Product Type | Servo Motors |
| Product | HG-SN202JK |
Mitsubishi Servo Motors HG-SN202JK Technical Specifications:
| Specification | Value |
|---|---|
| Series | MELSERVO-JE |
| Type | HG-SN |
| Power Supply (V) | 200 |
| Rated Capacity (kW) | 2 |
| Inertia | MEDIUM INERTIA |
| Rated Torque (Nm) | 9,55 |
| Maximum Torque (Nm) | 28,6 |
| Rated Speed (rpm) | 2000 |
| Inertia (kg*cm2) | 46,8 |
| Brake | NO |
| Shaft Type | KEYWAY |
| Current Type | AC |
| Encoder Resolution (p/rev) | 131072 |
| Maximum Speed (rpm) | 3000 |
| Protection Class | IP67 |
| Encoder Type | 17-BIT |
| Depth (mm) | 217,5 |
| Weight (kg) | 11 |
| Width (mm) | 176 |
| Height (mm) | 228,9 |
The Mitsubishi HG-SN202JK Servo Motor is a 2 kW medium inertia unit designed for reliable and consistent industrial automation tasks. With 9.55 Nm rated torque, 2000 rpm speed, and a 17-bit encoder providing 131072 p/rev resolution, it supports controlled and precise motion. As a part of the MELSERVO-JE series, the model is suited for environments requiring accurate position control and dependable torque stability.
This servo motor is used across conveyor systems, automated packaging machines, robotics axes, and assembly line mechanisms. Its combination of medium inertia, AC operation, and IP67 protection helps maintain performance in setups exposed to dust, vibration, or varying loads. The keyway shaft configuration allows secure mechanical coupling, ensuring stable rotation and predictable motion output in continuous-duty applications.
The Mitsubishi HG-SN202JK Servo Motor provides dependable torque delivery, accurate encoder feedback, and strong build quality for industrial environments. With Mitsubishiβs engineering reputation, the model integrates smoothly into motion systems that need repeatable positioning, long operating life, and consistent performance under demanding automation conditions.
